Schneider Electric EGB26050 Miniature Circuit Breaker 600V 50A

Schneider Electric EGB26050 Miniature Circuit Breaker 600V 50A

Schneider Electric
SKU:
EGB26050
|
UPC:
785901420965
Availability:
Contact us to confirm availability and lead times.
$647.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 50A, 2 pole, and has an operating voltage of 600Y/347 VAC. It also provides a 65 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This breaker was calibrated for 40 degrees C. This product is UL Listed as High Intensity Discharge. HACR rated.
Additional Information
Warranty:
18 months
Number Of Spaces:
2
Product Destination:
NF panelboard
Holding Current:
630 A
Trip Unit Technology:
thermal-magnetic
Height:
5.66 in
Mounting Mode:
bolt-on
Trip Unit Rating:
1800-1800 A
Width:
1.96 in
Product Or Component Type:
circuit-breaker
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Local Signalling:
trip indicator
Tightening Torque:
3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Rohs Exemption Information:
Yes
Module Type:
E-Frame
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Depth:
4.05 in
Ambient Air Temperature For Operation:
40 °C
Awg Gauge:
AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
Number Of Poles:
2
Device Short Name:
EGB
Protection Type:
overload || short-circuit
[Ue] Rated Operational Voltage:
600Y/347 V AC
Breaking Capacity:
18 kA 600Y/347 V AC
Number Of Spaces Required:
2
Range Of Product:
125 A Frame EDB-EGB-EJB
Product Certifications:
cULus
Net Weight:
3 lb(US)
Line Rated Current:
50 A
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Breaking Capacity Code:
G
Mercury Free:
Yes
Electrical Connection:
lugs aluminium
Circuit Breaker Application:
HACR rated
