Schneider Electric EJB14020SA Miniature Circuit Breaker 277V 20A

Schneider Electric EJB14020SA Miniature Circuit Breaker 277V 20A

Schneider Electric
SKU:
EJB14020SA
|
UPC:
3.60649E+12
Availability:
Contact us to confirm availability and lead times.
$1,163.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 20A, 1 pole, and has an operating voltage of 277 VAC. It also provides a 100 kA max interrupt rating at 120 VAC. This device has a hold current of 270A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 875A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This one includes a shunt trip. This breaker was calibrated for 40 degrees C. This product is UL Listed as Switching duty and High Intensity Discharge. HACR rated.
Additional Information
Tightening Torque:
3.4-3.4 N.m 2.5-16 mm² (AWG 14...AWG 6)
Circuit Breaker Application:
Switching Duty rated || HACR rated || HID rated
Product Certifications:
cULus
Protection Type:
overload || short-circuit
Net Weight:
2 lb(US)
Width:
1.96 in
Holding Current:
270 A
Depth:
4.05 in
Breaking Capacity:
65 kA 240 V AC || 65 kA 277 V AC || 100 kA 120 V AC || 65 kA 120/240 V AC
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Height:
5.66 in
Product Or Component Type:
miniature circuit-breaker
Range Of Product:
125 A Frame EDB-EGB-EJB
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Mounting Mode:
bolt-on
Mercury Free:
Yes
Rohs Exemption Information:
Yes
Warranty:
18 months
Ambient Air Temperature For Operation:
40 °C
Awg Gauge:
AWG 12...AWG 6 aluminium || AWG 14...AWG 6 copper
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Number Of Spaces:
2
Trip Unit Technology:
thermal-magnetic
Number Of Spaces Required:
2
Module Type:
E-Frame
Electrical Connection:
lugs aluminium
Device Short Name:
EJB
Line Rated Current:
20 A
Product Destination:
NF panelboard
Trip Unit Rating:
875-875 A
Local Signalling:
trip indicator
Breaking Capacity Code:
J
[Ue] Rated Operational Voltage:
277 V AC
Device Composition:
shunt trip
Number Of Poles:
1
