Schneider Electric EJB14060 Miniature Circuit Breaker 277V 60A
Schneider Electric
$408.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 60A, 1 pole, and has an operating voltage of 277 VAC. It also provides a 100 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This breaker was calibrated for 40 degrees C. HACR rated.
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Warranty:
- 18 months
- Awg Gauge:
- AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
- Line Rated Current:
- 60 A
- Protection Type:
- overload || short-circuit
- [Ue] Rated Operational Voltage:
- 277 V AC
- Mercury Free:
- Yes
- Net Weight:
- 2 lb(US)
- Local Signalling:
- trip indicator
- Tightening Torque:
- 3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
- Range Of Product:
- 125 A Frame EDB-EGB-EJB
- Holding Current:
- 630 A
- Electrical Connection:
- lugs aluminium
- Product Or Component Type:
- miniature circuit-breaker
- Device Short Name:
- EJB
- Module Type:
- E-Frame
- Number Of Poles:
- 1
- Width:
- 0.98 in
- Breaking Capacity Code:
- J
- Number Of Spaces Required:
- 1
- Ambient Air Temperature For Operation:
- 40 °C
- Product Certifications:
- cULus
- Depth:
- 4.05 in
- Mounting Mode:
- bolt-on
- Breaking Capacity:
- 65 kA 240 V AC || 65 kA 277 V AC || 100 kA 120 V AC || 65 kA 120/240 V AC
- Rohs Exemption Information:
- Yes
- Number Of Spaces:
- 1
- Trip Unit Rating:
- 1800-1800 A
- Height:
- 5.66 in
- Circuit Breaker Application:
- HACR rated
- Trip Unit Technology:
- thermal-magnetic
- Product Destination:
- NF panelboard
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
