Schneider Electric EJB14070 Miniature Circuit Breaker 277V 70A

(No reviews yet) Write a Review
SKU:
EJB14070
UPC:
7.85901E+11
Condition:
New
Protection Type:
short-circuit || overload
Line Rated Current:
70 A
Device Short Name:
EJB
Range Of Product:
125 A Frame EDB-EGB-EJB
Rohs Exemption Information:
Yes
Trip Unit Technology:
thermal-magnetic
Warranty:
18 months
Net Weight:
2 lb(US)
Local Signalling:
trip indicator
Height:
5.66 in
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Number Of Poles:
1
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Mercury Free:
Yes
Electrical Connection:
lugs aluminium
Breaking Capacity Code:
J
Ambient Air Temperature For Operation:
40 °C
Tightening Torque:
3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
Trip Unit Rating:
1800-1800 A
Product Certifications:
cULus
Product Destination:
NF panelboard
Awg Gauge:
AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
Depth:
4.05 in
Circuit Breaker Application:
HACR rated
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Module Type:
E-Frame
Product Or Component Type:
miniature circuit-breaker
Holding Current:
630 A
[Ue] Rated Operational Voltage:
277 V AC
Number Of Spaces Required:
1
Mounting Mode:
bolt-on
Breaking Capacity:
65 kA 240 V AC || 65 kA 277 V AC || 100 kA 120 V AC || 65 kA 120/240 V AC
Width:
0.98 in
Number Of Spaces:
1
Brochure:
View
Datasheet:
View
  • Schneider Electric EJB14070 Miniature Circuit Breaker 277V 70A
  • Schneider Electric EJB14070 Miniature Circuit Breaker 277V 70A
$812.00

Description

E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 70A, 1 pole, and has an operating voltage of 277 VAC. It also provides a 100 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This breaker was calibrated for 40 degrees C. HACR rated.
