Schneider Electric EJB16015 Miniature Circuit Breaker 600V 15A
Schneider Electric
$408.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 15A, 1 pole, and has an operating voltage of 600Y/347 VAC. It also provides a 100 kA max interrupt rating at 120 VAC. This device has a hold current of 270A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 875A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This breaker was calibrated for 40 degrees C. This product is UL Listed as Switching duty and High Intensity Discharge. HACR rated.
- Number Of Spaces:
- 1
- Circuit Breaker Application:
- HACR rated
- Breaking Capacity Code:
- J
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Warranty:
- 18 months
- Product Destination:
- NF panelboard
- Depth:
- 4.05 in
- Electrical Connection:
- lugs aluminium
- Width:
- 0.98 in
- Rohs Exemption Information:
- Yes
- Device Short Name:
- EJB
- [Ue] Rated Operational Voltage:
- 600Y/347 V AC
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Module Type:
- E-Frame
- Ambient Air Temperature For Operation:
- 40 °C
- Awg Gauge:
- AWG 12...AWG 6 aluminium || AWG 14...AWG 6 copper
- Holding Current:
- 270 A
- Protection Type:
- short-circuit || overload
- Tightening Torque:
- 3.4-3.4 N.m 2.5-16 mm² (AWG 14...AWG 6)
- Local Signalling:
- trip indicator
- Mounting Mode:
- bolt-on
- Height:
- 5.66 in
- Range Of Product:
- 125 A Frame EDB-EGB-EJB
- Line Rated Current:
- 15 A
- Mercury Free:
- Yes
- Product Certifications:
- cULus
- Breaking Capacity:
- 25 kA 600Y/347 V AC
- Product Or Component Type:
- circuit-breaker
- Number Of Poles:
- 1
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Trip Unit Rating:
- 875-875 A
- Trip Unit Technology:
- thermal-magnetic
- Net Weight:
- 2 lb(US)
- Number Of Spaces Required:
- 1
