Schneider Electric EJB26050 Miniature Circuit Breaker 600V 50A
Schneider Electric
$1,552.50
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric EJB26050 Miniature Circuit Breaker 600V 50A
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 50A, 2 pole, and has an operating voltage of 600Y/347 VAC. It also provides a 100 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This breaker was calibrated for 40 degrees C. This product is UL Listed as High Intensity Discharge. HACR rated.
- Line Rated Current:
- 50 A
- Product Destination:
- NF panelboard
- Trip Unit Technology:
- thermal-magnetic
- Number Of Spaces:
- 2
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Warranty:
- 18 months
- Holding Current:
- 630 A
- Range Of Product:
- 125 A Frame EDB-EGB-EJB
- Awg Gauge:
- AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
- Breaking Capacity Code:
- J
- Electrical Connection:
- lugs aluminium
- Net Weight:
- 3 lb(US)
- Tightening Torque:
- 3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
- Rohs Exemption Information:
- Yes
- Breaking Capacity:
- 25 kA 600Y/347 V AC
- Mounting Mode:
- bolt-on
- Circuit Breaker Application:
- HACR rated
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Depth:
- 4.05 in
- Protection Type:
- short-circuit || overload
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Product Or Component Type:
- circuit-breaker
- Local Signalling:
- trip indicator
- Module Type:
- E-Frame
- Trip Unit Rating:
- 1800-1800 A
- Mercury Free:
- Yes
- Height:
- 5.66 in
- Product Certifications:
- cULus
- Number Of Spaces Required:
- 2
- [Ue] Rated Operational Voltage:
- 600Y/347 V AC
- Device Short Name:
- EJB
- Width:
- 1.96 in
- Ambient Air Temperature For Operation:
- 40 °C
- Number Of Poles:
- 2
