Schneider Electric EJB34035 Miniature Circuit Breaker 480Y/277V 35A

(No reviews yet) Write a Review
SKU:
EJB34035
UPC:
785901130611
Condition:
New
Circuit Breaker Application:
HID rated || HACR rated
Trip Unit Technology:
thermal-magnetic
Depth:
4.05 in
Trip Unit Rating:
1800-1800 A
Protection Type:
overload || short-circuit
Tightening Torque:
3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
Electrical Connection:
lugs aluminium
Holding Current:
630 A
Ambient Air Temperature For Operation:
40 °C
Width:
2.94 in
Breaking Capacity:
65 kA 277 V AC || 100 kA 240 V AC || 65 kA 480Y/277 V AC || 100 kA 120 V AC || 100 kA 120/240 V AC
Breaking Capacity Code:
J
Mounting Mode:
bolt-on
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Device Short Name:
EJB
Module Type:
E-Frame
Line Rated Current:
35 A
Product Certifications:
cULus
Number Of Poles:
3
Product Destination:
NF panelboard
Number Of Spaces:
3
Awg Gauge:
AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Mercury Free:
Yes
Product Or Component Type:
miniature circuit-breaker
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Rohs Exemption Information:
Yes
Local Signalling:
trip indicator
Net Weight:
4 lb(US)
Warranty:
18 months
Number Of Spaces Required:
3
Height:
5.66 in
[Ue] Rated Operational Voltage:
480Y/277 V AC
Range Of Product:
125 A Frame EDB-EGB-EJB
  • Schneider Electric EJB34035 Miniature Circuit Breaker 480Y/277V 35A
  • Schneider Electric EJB34035 Miniature Circuit Breaker 480Y/277V 35A
  • Schneider Electric EJB34035 Miniature Circuit Breaker 480Y/277V 35A
$1,358.00

Description

E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 35A, 3 pole, and has an operating voltage of 480Y/277 VAC. It also provides a 100 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This breaker was calibrated for 40 degrees C. This product is UL Listed as High Intensity Discharge. HACR rated.
