Schneider Electric GV2AP03 External Operator

Schneider Electric GV2AP03 External Operator

Schneider Electric
SKU:
GV2AP03
|
UPC:
3389110573923
Availability:
Contact us to confirm availability and lead times.
$135.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
TeSys GV extended rotary handle, for motor circuit breakers GV2LE, GV2RT mounted inside an enclosure and to be operated externally. For main switch usage, it provides a black handle on grey front plate with indication of 2 positions OFF, ON. To be mounted on the door of the enclosure, the handle mechanism ensures an IP54 protection to the mounting. It also includes a mounting adaptor to be screwed on the face of the circuit breaker, and an extension shaft to be be adjusted in length (distance between the door and the back of the circuit breaker must be in range 141-290mm). Padlockable in OFF or ON position with up to 3 padlocks (to be ordered separately). Locking in ON position does not prevent the circuit breaker from tripping (unlocking is required for fault reset). Green Premium compliant (RoHS/REACh).
Additional Information
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Ip Degree Of Protection:
IP54
Rotary Handle Padlocking:
padlock in OFF position || padlock in ON position
Device Short Name:
GV2AP
Product Or Component Type:
rotary handle kit
Product Compatibility:
GV2RT || GV2LE
Handle Front Plate Colour:
blue
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Back/Door Distance:
135-282 mm
Range:
TeSys
Eu Rohs Directive:
Compliant with Exemptions
Rohs Exemption Information:
Yes
Handle Colour:
black
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Accessory / Separate Part Category:
control accessory
Locking Options Description:
1 to 3 padlocks
Warranty:
18 months
Rotary Handle Mounting Style:
extended
Mercury Free:
Yes
Net Weight:
0.28 kg
Datasheet:
View
