Schneider Electric GV2ME08 Tesys M-Cb Tho/Mag 2.5-4A Rocker

Schneider Electric GV2ME08 Tesys M-Cb Tho/Mag 2.5-4A Rocker

Schneider Electric
SKU:
GV2ME08
|
UPC:
3389110343090
$180.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
The GV2 manual starter and protector provides manual isolation, manual motor control, and thermal overcurrent protection in one compact unit. The basic motor starter GV2ME controls motors with full load currents up to 32 A. The manual starter is three pole with horsepower ratings. The manual starter is operated by push buttons. The Class 10 ambient compensated thermal over current is adjustable from 2.5 ampere to 4 ampere. This device has screw clamp terminals. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine, ATEX), Green Premium compliant (RoHS/REACh).
Additional Information
Warranty:
18 months
Mercury Free:
Yes
Width:
45 mm
Eu Rohs Directive:
Compliant with Exemptions
Poles Description:
3P
Net Weight:
0.26 kg
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-2
Power Dissipation Per Pole:
2.5 W
[Ics] Rated Service Short-Circuit Breaking Capacity:
100 % 230/240 V AC 50/60 Hz IEC 60947-2 || 100 % 400/415 V AC 50/60 Hz IEC 60947-2 || 100 % 440 V AC 50/60 Hz IEC 60947-2 || 100 % 500 V AC 50/60 Hz IEC 60947-2 || 75 % 690 V AC 50/60 Hz IEC 60947-2
Sustainable Offer Status:
Green Premium product
Rohs Exemption Information:
Yes
Circularity Profile:
ENVEOLI121004
Ambient Air Temperature For Storage:
-40-80 °C
Color:
dark grey
Product Name:
TeSys GV2 || TeSys Deca
Motor Power Kw:
1.1-1.1 kW 400/415 V AC 50/60 Hz || 1.5-1.5 kW 400/415 V AC 50/60 Hz || 1.5-1.5 kW 500 V AC 50/60 Hz || 2.2-2.2 kW 500 V AC 50/60 Hz || 3-3 kW 690 V AC 50/60 Hz || 2.2-2.2 kW 690 V AC 50/60 Hz
Rated Duty:
continuous IEC 60947-4-1
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Magnetic Tripping Current:
51-51 A
Suitability For Isolation:
yes IEC 60947-1 § 7-1-6
Breaking Capacity:
100 kA Icu 230/240 V AC 50/60 Hz IEC 60947-2 || 100 kA Icu 400/415 V AC 50/60 Hz IEC 60947-2 || 100 kA Icu 440 V AC 50/60 Hz IEC 60947-2 || 100 kA Icu 500 V AC 50/60 Hz IEC 60947-2 || 3 kA Icu 690 V AC 50/60 Hz IEC 60947-2
[Ith] Conventional Free Air Thermal Current:
4 A IEC 60947-4-1
Climatic Withstand:
IACS E10
Ambient Air Temperature For Operation:
-20-60 °C
Network Type:
AC
Phase Failure Sensitivity:
yes IEC 60947-4-1
Network Frequency:
50/60 Hz IEC 60947-4-1
Environmental Disclosure:
ENVPEP121004
Operating Altitude:
6561.68 ft (2000 m)
Ik Degree Of Protection:
IK04
Device Application:
motor protection
Line Rated Current:
0.166666666666667
Device Short Name:
GV2ME
Fire Resistance:
960 °C IEC 60695-2-11
Product Certifications:
CCC || UL || CSA || EAC || ATEX || LROS (Lloyds register of shipping) || BV || RINA || DNV-GL || UKCA
Thermal Protection Adjustment Range:
2.5-4 A IEC 60947-4-1
Tightening Torque:
1.7 N.m screw clamp terminal
Ip Degree Of Protection:
IP20 IEC 60529
Height:
89 mm
Control Type:
push-button
Standards:
EN/IEC 60947-2 || EN/IEC 60947-4-1
Mechanical Robustness:
shocks 30 Gn for 11 ms || vibrations 5 Gn, 5...150 Hz
Electrical Durability:
100000 cycles AC-3 415 V In || 100000 cycles AC-3e 415 V In
Depth:
78.5 mm
Fixing Mode:
35 mm symmetrical DIN rail clipped || panel screwed with adaptor plate)
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
California Proposition 65:
WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
Product Or Component Type:
motor circuit breaker
[Uimp] Rated Impulse Withstand Voltage:
6 kV IEC 60947-2
Range:
TeSys Deca
[Ui] Rated Insulation Voltage:
690 V AC 50/60 Hz IEC 60947-2
Utilisation Category:
category A IEC 60947-2 || AC-3 IEC 60947-4-1 || AC-3e IEC 60947-4-1
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Mechanical Durability:
100000 cycles
Trip Unit Technology:
thermal-magnetic
Datasheet:
View
