Schneider Electric GV4AU027 Coil Uvr Mn 24V Ac/Dc For Gv4 Bv4

Schneider Electric GV4AU027 Coil Uvr Mn 24V Ac/Dc For Gv4 Bv4

Schneider Electric
SKU:
GV4AU027
|
UPC:
3606485444819
Availability:
Contact us to confirm availability and lead times.
$277.50
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
TeSys GV electrical trip unit, MN undervoltage release, 24V AC 50/60Hz and 24V DC, for motor circuit breakers GV4. Opening of the the circuit breaker is ensured when the control voltage drops below 0.35 Uc, and possible between 0.35-0.7 Uc. Closing of the circuit breaker is possible when the control voltage is in limits 0.85-1.1 Uc. To be plugged inside the circuit breaker, connection by spring terminals. Multi standards certified (IEC, UL, CSA), Green Premium compliant (RoHS/REACh).
Additional Information
Mechanical Durability:
20000 cycles
[Uc] Control Circuit Voltage:
24 V AC 50/60 Hz || 24 V DC
Mercury Free:
Yes
Wire Stripping Length:
8 mm
Connections - Terminals:
spring terminals 1 0.5-1.5 mm² - cable stiffness: flexible without cable end
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Maximum Hold-In Power Consumption In W:
2 W
Mounting Mode:
internal mounting
[Ui] Rated Insulation Voltage:
24 V IEC 60947-1
Maximum Inrush Power In W:
2 W
Voltage Release Type:
undervoltage release
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Range Compatibility:
TeSys TeSys GV4 || TeSys TeSys BV4
Environmental Disclosure:
ENVPEP2311042EN
Circularity Profile:
ENVEOLI2311042EN
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Rohs Exemption Information:
Yes
Eu Rohs Directive:
Compliant with Exemptions
Operating Time:
< 50 ms
Maximum Inrush Power In Va:
7 VA
Maximum Hold-In Power Consumption In Va:
7 VA
Product Or Component Type:
voltage release
Device Application:
control
Device Short Name:
MN
Quantity Per Set:
set of 1
Threshold Tripping Voltage:
< 0.35 Un failsafe opening || 0.35...0.7 Un possible opening || 0.85...1.1 Un enabled closing
Range:
TeSys
