Schneider Electric GV4AU247 Coil Uvr Mn 208-240V 50/60Hz For Gv4 Bv4

Schneider Electric GV4AU247 Coil Uvr Mn 208-240V 50/60Hz For Gv4 Bv4

Schneider Electric
SKU:
GV4AU247
|
UPC:
3.60649E+12
Availability:
Contact us to confirm availability and lead times.
$277.50
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
TeSys GV electrical trip unit, MN undervoltage release, 208-240V AC 50/60Hz, for motor circuit breakers GV4. Opening of the the circuit breaker is ensured when the control voltage drops below 0.35 Uc, and possible between 0.35-0.7 Uc. Closing of the circuit breaker is possible when the control voltage is in limits 0.85-1.1 Uc. To be plugged inside the circuit breaker, connection by spring terminals. Multi standards certified (IEC, UL, CSA), Green Premium compliant (RoHS/REACh).
Additional Information
Rohs Exemption Information:
Yes
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Range:
TeSys
Connections - Terminals:
spring terminals 1 0.5-1.5 mm² - cable stiffness: flexible without cable end
Range Compatibility:
TeSys TeSys GV4 || TeSys TeSys BV4
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Quantity Per Set:
set of 1
Threshold Tripping Voltage:
< 0.35 Un failsafe opening || 0.35...0.7 Un possible opening || 0.85...1.1 Un enabled closing
Operating Time:
< 50 ms
[Uc] Control Circuit Voltage:
220...240 V AC 50 Hz || 208...240 V AC 60 Hz
Wire Stripping Length:
8 mm
Mounting Mode:
internal mounting
Maximum Hold-In Power Consumption In Va:
7 VA
Voltage Release Type:
undervoltage release
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Mechanical Durability:
20000 cycles
Device Short Name:
MN
Product Or Component Type:
voltage release
Maximum Inrush Power In Va:
7 VA
Circularity Profile:
ENVEOLI2311042EN
Environmental Disclosure:
ENVPEP2311042EN
[Ui] Rated Insulation Voltage:
240 V IEC 60947-1
Device Application:
control
Eu Rohs Directive:
Compliant with Exemptions
Mercury Free:
Yes
