Schneider Electric GV7AP02 Long Rotary Actuator
Schneider Electric
Schneider Electric GV7AP01 Lang Rotary Actuator Blac
Schneider Electric
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
GV7AP01 is an extended rotary handle for TeSys GV7 motor circuit breakers from Schneider Electric. Compatible with all GV7 models, it operates externally front face a circuit breaker installed inside a cabinet. Black handle, for main switch usage. GV7AP01 is an extended rotary handle for TeSys GV7 motor circuit breakers from Schneider Electric. Compatible with all GV7 models, it allows a circuit breaker installed inside a cabinet to be operated externally front face. It includes an adaptor for the face of the circuit breaker, a black handle with grey front plate to be door mounted and an extension shaft adjustable in length. It is intended for main switch usage, ensures IP55 protection and is padlockable. Extended rotary handle for the external operation of a circuit breaker installed inside a cabinet. The extension shaft can be adjusted for a distance of 185mm to 600mm between the mounting surface of the circuit breaker and the external door surface. Black handle with grey front plate for main switch applications. Ensure IP55 protection. Padlockable with 3 padlocks in the Off position, prevents the door to be opened.
- Ip Degree Of Protection:
- IP55
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Back/Door Distance:
- 185-600 mm
- Rotary Handle Mounting Style:
- extended
- Eu Rohs Directive:
- Compliant with Exemptions
- Range:
- TeSys
- Device Short Name:
- GV7AP
- Net Weight:
- 0.775 kg
- Sustainable Offer Status:
- Green Premium product
- Rohs Exemption Information:
- Yes
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Product Or Component Type:
- extended rotary handle
- Rotary Handle Mounting Location:
- front
- Accessory / Separate Part Category:
- control accessory
- Circularity Profile:
- ENVEOLI1905002EN
- Handle Front Plate Colour:
- black
- Warranty:
- 18 months
- Handle Colour:
- black
- Range Compatibility:
- TeSys TeSys GV7 motor circuit breaker || TeSys TeSys GV5 motor circuit breaker
- Mercury Free:
- Yes
- Environmental Disclosure:
- ENVPEP1905002EN
- Catalog:
- View
- Datasheet:
- View
- QN-QUOTE-REQUEST:
- true
