Schneider Electric HDA36150SA Molded Case Circuit Breaker 600V 150A

Schneider Electric HDA36150SA Molded Case Circuit Breaker 600V 150A

Schneider Electric
SKU:
HDA36150SA
|
UPC:
785901324102
Availability:
Contact us to confirm availability and lead times.
$3,447.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. PowerPacT H I-Line circuit breakers are available in I-Line construction for easy installation and removal in I-Line applications. This breaker has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT H, 150A, 3 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 80% with an ABC phase connection. This unit includes a factory installed 120VAC shunt trip. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Mounting Height:
4.5 in
Ambient Air Temperature For Operation:
-2-70 °C
Pvc Free:
Yes
Accessory / Separate Part Type:
shunt trip 110...130 V AC compartment
Terminal Identifier:
AL150HD
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
[Ics] Rated Service Breaking Capacity:
25 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Product Certifications:
UL || CSA || NOM
Range:
PowerPact
Electrical Connection:
I-Line connection, line || lugs, load
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Warranty:
18 months
Phase Connection:
ABC
Mercury Free:
Yes
Ip Degree Of Protection:
front cover IP40 IEC 60529
Product Name:
PowerPact H
Control Type:
toggle
Continuous Current Rating:
0.8
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Circularity Profile:
ENVEOLI2206027EN
Eu Rohs Directive:
Compliant with Exemptions
Breaking Capacity Code:
D
Magnetic Hold Current:
900 A
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Device Application:
distribution
Breaking Capacity:
25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC
Quality Labels:
CE
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Pollution Degree:
3 IEC 60947-1
Net Weight:
2.2 kg
Sustainable Offer Status:
Green Premium product
Wire Stripping Length:
16 mm
Product Or Component Type:
circuit breaker
Mounting Support:
bracket
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Trip Unit Technology:
thermal-magnetic
Mounting Mode:
I-Line bracket)
Poles Description:
3P
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Depth:
86 mm
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Communication Interface:
Modbus || Ethernet
Quantity Per Set:
1
Utilisation Category:
category A
Protected Poles Description:
3t
Rohs Exemption Information:
Yes
Ambient Air Temperature For Storage:
-50-85 °C
Environmental Disclosure:
ENVPEP2206027EN
Color:
Black
Suitability For Isolation:
yes IEC 60947-2
Line Rated Current:
150-150 A
Width:
104 mm
Height:
163 mm
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Circuit Breaker Application:
HACR rated
Magnetic Tripping Current:
1700-1700 A
Network Frequency:
50/60 Hz
Local Signalling:
switched off (OFF) 1 trip indicator green)
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
