Schneider Electric HDF36110 Molded Case Circuit Breaker 600V 110A

Schneider Electric HDF36110 Molded Case Circuit Breaker 600V 110A

Schneider Electric
SKU:
HDF36110
|
UPC:
7.85902E+11
Availability:
Contact us to confirm availability and lead times.
$2,600.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has a busbar connection. This PowerPacT H, 110A, 3 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Pvc Free:
Yes
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Ambient Air Temperature For Storage:
-50-85 °C
Sustainable Offer Status:
Green Premium product
Circularity Profile:
ENVEOLI2206027EN
Terminal Identifier:
AL150HD
Quality Labels:
CE
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Breaking Capacity Code:
D
Ip Degree Of Protection:
front cover IP40 IEC 60529
Warranty:
18 months
Depth:
86 mm
Magnetic Hold Current:
900 A
[Ics] Rated Service Breaking Capacity:
25 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Network Frequency:
50/60 Hz
Mercury Free:
Yes
Electrical Connection:
busbar connection, line || busbar connection, load
Wire Stripping Length:
16 mm
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Poles Description:
3P
Rohs Exemption Information:
Yes
Product Certifications:
UL || CSA || NOM
Product Name:
PowerPact H
Mounting Support:
busbar
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Trip Unit Technology:
thermal-magnetic
Control Type:
toggle
Continuous Current Rating:
0.8
Width:
104 mm
Net Weight:
2.2 kg
Environmental Disclosure:
ENVPEP2206027EN
Device Application:
distribution
Eu Rohs Directive:
Compliant with Exemptions
Pollution Degree:
3 IEC 60947-1
Height:
163 mm
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Product Or Component Type:
circuit breaker
Ambient Air Temperature For Operation:
-2-70 °C
Communication Interface:
Modbus || Ethernet
Local Signalling:
switched off (OFF) 1 trip indicator green)
Color:
Black
Range:
PowerPact
Utilisation Category:
category A
Protected Poles Description:
3t
Circuit Breaker Application:
HACR rated
Suitability For Isolation:
yes IEC 60947-2
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Breaking Capacity:
25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC
Line Rated Current:
110-110 A
Mounting Mode:
unit mount busbar)
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Quantity Per Set:
1
Magnetic Tripping Current:
1700-1700 A
