Schneider Electric HDL26040C Molded Case Circuit Breaker 600V 40A
Schneider Electric
$2,349.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric HDL26040C Molded Case Circuit Breaker 600V 40A
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 40A, 2 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 100%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
- Range:
- PowerPact
- [Ui] Rated Insulation Voltage:
- 750 V IEC 60947-2
- Breaking Capacity Code:
- D
- Product Name:
- PowerPact H
- Tightening Torque:
- 5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
- Sustainable Offer Status:
- Green Premium product
- Height:
- 163 mm
- Ambient Air Temperature For Operation:
- -2-70 °C
- Mounting Mode:
- unit mount lug)
- Environmental Disclosure:
- ENVPEP1311006EN
- Breaking Capacity:
- 25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC
- Quality Labels:
- CE
- Standards:
- UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
- Trip Unit Technology:
- thermal-magnetic
- Color:
- Black
- Poles Description:
- 2P
- Terminal Identifier:
- AL150HD
- [Ics] Rated Service Breaking Capacity:
- 25 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
- Pvc Free:
- Yes
- Magnetic Tripping Current:
- 850-850 A
- Communication Interface:
- Modbus || Ethernet
- Continuous Current Rating:
- 1
- [Ue] Rated Operational Voltage:
- 690 V AC 50/60 Hz IEC 60947-3
- Number Of Slots:
- 2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
- Magnetic Hold Current:
- 400 A
- Circularity Profile:
- ENVEOLI1311006EN
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Network Frequency:
- 50/60 Hz
- Pollution Degree:
- 3 IEC 60947-1
- Line Rated Current:
- 40-40 A
- Net Weight:
- 2.2 kg
- Circuit Breaker Application:
- HACR rated
- Device Application:
- distribution
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
- Protected Poles Description:
- 2t
- Ip Degree Of Protection:
- front cover IP40 IEC 60529
- Control Type:
- toggle
- Mounting Support:
- lug
- Awg Gauge:
- AWG 14...AWG 3/0 aluminium/copper terminal
- Width:
- 104 mm
- Suitability For Isolation:
- yes IEC 60947-2
- Warranty:
- 18 months
- Eu Rohs Directive:
- Compliant
- Operating Altitude:
- < 6561.68 ft (2000 m) without derating || 5000 m with derating
- Product Certifications:
- UL || CSA || NOM
- Electrical Connection:
- lugs, line || lugs, load
- Local Signalling:
- switched off (OFF) 1 trip indicator green)
- [Uimp] Rated Impulse Withstand Voltage:
- 8 kV IEC 60947-2
- Product Or Component Type:
- circuit breaker
- Mercury Free:
- Yes
- Utilisation Category:
- category A
- Quantity Per Set:
- 1
- Rohs Exemption Information:
- Yes
- Ambient Air Temperature For Storage:
- -50-85 °C
- Wire Stripping Length:
- 16 mm
- Depth:
- 86 mm
