Schneider Electric HDL36015C Molded Case Circuit Breaker 600V 15A
Schneider Electric
$1,305.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric HDL36015C Molded Case Circuit Breaker 600V 15A
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 15A, 3 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 100%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
- Mounting Support:
- lug
- Depth:
- 86 mm
- Rohs Exemption Information:
- Yes
- Product Name:
- PowerPact H
- Wire Stripping Length:
- 16 mm
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Quality Labels:
- CE
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Quantity Per Set:
- 1
- [Ui] Rated Insulation Voltage:
- 750 V IEC 60947-2
- Utilisation Category:
- category A
- Color:
- Black
- Magnetic Hold Current:
- 350 A
- Local Signalling:
- switched off (OFF) 1 trip indicator green)
- Line Rated Current:
- 15-15 A
- Breaking Capacity Code:
- D
- Ambient Air Temperature For Operation:
- -2-70 °C
- Pvc Free:
- Yes
- Width:
- 104 mm
- Electrical Connection:
- lugs, line || lugs, load
- Eu Rohs Directive:
- Compliant with Exemptions
- Environmental Disclosure:
- ENVPEP2206027EN
- Communication Interface:
- Modbus || Ethernet
- Awg Gauge:
- AWG 14...AWG 3/0 aluminium/copper terminal
- [Ics] Rated Service Breaking Capacity:
- 25 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
- Breaking Capacity:
- 25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC
- Device Application:
- distribution
- Product Or Component Type:
- circuit breaker
- Operating Altitude:
- < 6561.68 ft (2000 m) without derating || 5000 m with derating
- Trip Unit Technology:
- thermal-magnetic
- Sustainable Offer Status:
- Green Premium product
- Net Weight:
- 2.2 kg
- Height:
- 163 mm
- Suitability For Isolation:
- yes IEC 60947-2
- Poles Description:
- 3P
- Ip Degree Of Protection:
- front cover IP40 IEC 60529
- Standards:
- UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
- Continuous Current Rating:
- 1
- Ambient Air Temperature For Storage:
- -50-85 °C
- Range:
- PowerPact
- Pollution Degree:
- 3 IEC 60947-1
- Network Frequency:
- 50/60 Hz
- Mounting Mode:
- unit mount lug)
- Warranty:
- 18 months
- Magnetic Tripping Current:
- 750-750 A
- Circuit Breaker Application:
- HACR rated
- [Uimp] Rated Impulse Withstand Voltage:
- 8 kV IEC 60947-2
- Terminal Identifier:
- AL150HD
- Mercury Free:
- Yes
- Protected Poles Description:
- 3t
- [Ue] Rated Operational Voltage:
- 690 V AC 50/60 Hz IEC 60947-3
- Circularity Profile:
- ENVEOLI2206027EN
- Number Of Slots:
- 2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
- Control Type:
- toggle
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
- Product Certifications:
- UL || CSA || NOM
- Tightening Torque:
- 5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
