Schneider Electric HDL36060U44X Molded Case Circuit Breaker 600V 60A

Schneider Electric HDL36060U44X Molded Case Circuit Breaker 600V 60A

Schneider Electric
SKU:
HDL36060U44X
|
UPC:
785901458807
Availability:
Factory stock
$2,569.02
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides Micrologic Ammeter with a 6.2A trip unit and an LSIG function with a breaking capacity of 14kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 60A, 3 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Device Application:
distribution
Protected Poles Description:
3t
Mercury Free:
Yes
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Width:
104 mm
Ip Degree Of Protection:
front cover IP40 IEC 60529
Height:
163 mm
Product Or Component Type:
circuit breaker
Range:
PowerPact
Trip Unit Name:
MicroLogic 6.2 A
Wire Stripping Length:
16 mm
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Long Time Pick-Up Adjustment Range:
0.25...1 x In
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Quantity Per Set:
1
Pvc Free:
Yes
Breaking Capacity:
25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC
Sustainable Offer Status:
Green Premium product
Breaking Capacity Code:
D
Product Name:
PowerPact H
Circularity Profile:
ENVEOLI2206028EN
Trip Unit Technology:
electronic, ammeter, MicroLogic 6.2 A, LSIG
Rohs Exemption Information:
Yes
Color:
Black
Line Rated Current:
60-60 A
Quality Labels:
CE
Electrical Connection:
lugs, line || lugs, load
Poles Description:
3P
Ambient Air Temperature For Operation:
-2-70 °C
Control Type:
toggle
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Warranty:
18 months
Product Certifications:
UL || CSA || NOM
Pollution Degree:
3 IEC 60947-1
Net Weight:
2.2 kg
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Environmental Disclosure:
ENVPEP2206028EN
Continuous Current Rating:
0.8
Mounting Mode:
unit mount lug)
Local Signalling:
ready 1 LED green) || alarm 1 LED 90 % Ir orange) || alarm LED 105 % Ir red) || switched off (OFF) 1 trip indicator green)
[Ics] Rated Service Breaking Capacity:
25 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Ambient Air Temperature For Storage:
-50-85 °C
Depth:
86 mm
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Terminal Identifier:
AL150HD
Suitability For Isolation:
yes IEC 60947-2
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Mounting Support:
lug
Network Frequency:
50/60 Hz
Circuit Breaker Application:
HACR rated
Eu Rohs Directive:
Compliant with Exemptions
Utilisation Category:
category A
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Communication Interface:
Modbus || Ethernet
