Schneider Electric HDL36100AA Molded Case Circuit Breaker 600V 100A

Schneider Electric HDL36100AA Molded Case Circuit Breaker 600V 100A

Schneider Electric
SKU:
HDL36100AA
|
UPC:
785901333876
Availability:
Factory stock
$1,553.54
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 100A, 3 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 80%. This unit includes a factory installed 1A/1B auxiliary switch. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Mounting Support:
lug
Eu Rohs Directive:
Compliant with Exemptions
Circuit Breaker Application:
HACR rated
Trip Unit Technology:
thermal-magnetic
Color:
Black
Utilisation Category:
category A
Communication Interface:
Modbus || Ethernet
Poles Description:
3P
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Warranty:
18 months
Electrical Connection:
lugs, line || lugs, load
Mounting Mode:
unit mount lug)
[Ics] Rated Service Breaking Capacity:
25 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Control Type:
toggle
Magnetic Tripping Current:
1700-1700 A
Range:
PowerPact
Network Frequency:
50/60 Hz
Mercury Free:
Yes
Quantity Per Set:
1
Net Weight:
2.2 kg
Product Certifications:
UL || CSA || NOM
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Protected Poles Description:
3t
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Continuous Current Rating:
0.8
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Accessory / Separate Part Type:
auxiliary switch 24 V AC/DC 1 NO + 1 NC cover frame
Line Rated Current:
100-100 A
Quality Labels:
CE
Environmental Disclosure:
ENVPEP2206027EN
Product Or Component Type:
circuit breaker
Pollution Degree:
3 IEC 60947-1
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Ip Degree Of Protection:
front cover IP40 IEC 60529
Height:
163 mm
Depth:
86 mm
Width:
104 mm
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Ambient Air Temperature For Storage:
-50-85 °C
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Magnetic Hold Current:
900 A
Circularity Profile:
ENVEOLI2206027EN
Terminal Identifier:
AL150HD
Ambient Air Temperature For Operation:
-2-70 °C
Breaking Capacity:
25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC
Pvc Free:
Yes
Suitability For Isolation:
yes IEC 60947-2
Device Application:
distribution
Breaking Capacity Code:
D
Sustainable Offer Status:
Green Premium product
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Rohs Exemption Information:
Yes
Local Signalling:
switched off (OFF) 1 trip indicator green)
Wire Stripping Length:
16 mm
Product Name:
PowerPact H
