Schneider Electric HDL36110SA Molded Case Circuit Breaker 600V 110A

Schneider Electric HDL36110SA Molded Case Circuit Breaker 600V 110A

Schneider Electric
SKU:
HDL36110SA
|
UPC:
7.85902E+11
Availability:
Contact us to confirm availability and lead times.
$4,975.50
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 110A, 3 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 80%. This unit includes a factory installed 120VAC shunt trip. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Range:
PowerPact
Magnetic Hold Current:
900 A
Environmental Disclosure:
ENVPEP1311006EN
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Breaking Capacity Code:
D
Width:
104 mm
Product Name:
PowerPact H
Product Certifications:
UL || CSA || NOM
Communication Interface:
Modbus || Ethernet
Continuous Current Rating:
0.8
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Line Rated Current:
110-110 A
Poles Description:
3P
Suitability For Isolation:
yes IEC 60947-2
Product Or Component Type:
circuit breaker
Device Application:
distribution
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Quantity Per Set:
1
Terminal Identifier:
AL150HD
Warranty:
18 months
Mercury Free:
Yes
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Rohs Exemption Information:
Yes
Accessory / Separate Part Type:
shunt trip 110...130 V AC compartment
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Eu Rohs Directive:
Compliant
Control Type:
toggle
Network Frequency:
50/60 Hz
Electrical Connection:
lugs, line || lugs, load
Circuit Breaker Application:
HACR rated
Pvc Free:
Yes
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Height:
163 mm
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Color:
Black
Magnetic Tripping Current:
1700-1700 A
Sustainable Offer Status:
Green Premium product
Ambient Air Temperature For Storage:
-50-85 °C
Mounting Mode:
unit mount lug)
Mounting Support:
lug
Protected Poles Description:
3t
Ip Degree Of Protection:
front cover IP40 IEC 60529
Net Weight:
2.2 kg
Local Signalling:
switched off (OFF) 1 trip indicator green)
Quality Labels:
CE
Ambient Air Temperature For Operation:
-2-70 °C
Circularity Profile:
ENVEOLI1311006EN
[Ics] Rated Service Breaking Capacity:
25 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Pollution Degree:
3 IEC 60947-1
Trip Unit Technology:
thermal-magnetic
Wire Stripping Length:
16 mm
Depth:
86 mm
Breaking Capacity:
25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC
Utilisation Category:
category A
