Schneider Electric HDM36040 Molded Case Circuit Breaker 600V 40A

Schneider Electric HDM36040 Molded Case Circuit Breaker 600V 40A

Schneider Electric
SKU:
HDM36040
|
UPC:
3606486282182
Availability:
Contact us to confirm availability and lead times.
$1,632.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on the line and terminal nuts on the load side. This PowerPacT H, 40A, 3 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
[Ics] Rated Service Breaking Capacity:
25 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Circuit Breaker Application:
HACR rated
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Environmental Disclosure:
ENVPEP2206027EN
Protected Poles Description:
3t
Suitability For Isolation:
yes IEC 60947-2
Network Frequency:
50/60 Hz
Height:
163 mm
Breaking Capacity Code:
D
Local Signalling:
switched off (OFF) 1 trip indicator green)
Pvc Free:
Yes
Sustainable Offer Status:
Green Premium product
Warranty:
18 months
Depth:
86 mm
Color:
Black
Continuous Current Rating:
0.8
Trip Unit Technology:
thermal-magnetic
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Poles Description:
3P
Line Rated Current:
40-40 A
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Wire Stripping Length:
16 mm
Magnetic Tripping Current:
850-850 A
Ambient Air Temperature For Operation:
-2-70 °C
Range:
PowerPact
Ambient Air Temperature For Storage:
-50-85 °C
Mounting Mode:
unit mount lug)
Product Certifications:
UL || CSA || NOM
Utilisation Category:
category A
Quantity Per Set:
1
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Device Application:
distribution
Ip Degree Of Protection:
front cover IP40 IEC 60529
Breaking Capacity:
25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC
Control Type:
toggle
Electrical Connection:
lugs, line || terminal nut, load
Circularity Profile:
ENVEOLI2206027EN
Net Weight:
2.2 kg
Rohs Exemption Information:
Yes
Pollution Degree:
3 IEC 60947-1
Magnetic Hold Current:
400 A
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Product Or Component Type:
circuit breaker
Mercury Free:
Yes
Communication Interface:
Modbus || Ethernet
Product Name:
PowerPact H
Mounting Support:
lug
Quality Labels:
CE
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Width:
104 mm
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Terminal Identifier:
AL150HD
Eu Rohs Directive:
Compliant with Exemptions
