Schneider Electric HDP36050 Molded Case Circuit Breaker 600V 50A
Schneider Electric
$1,088.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric HDP36050 Molded Case Circuit Breaker 600V 50A
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has terminal nuts on the line side and lugs on the load side. This PowerPacT H, 50A, 3 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
- Width:
- 104 mm
- Protected Poles Description:
- 3t
- [Ue] Rated Operational Voltage:
- 690 V AC 50/60 Hz IEC 60947-3
- Device Application:
- distribution
- Ambient Air Temperature For Storage:
- -50-85 °C
- [Ics] Rated Service Breaking Capacity:
- 25 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
- Operating Altitude:
- < 6561.68 ft (2000 m) without derating || 5000 m with derating
- Communication Interface:
- Modbus || Ethernet
- Control Type:
- toggle
- Magnetic Tripping Current:
- 850-850 A
- Network Frequency:
- 50/60 Hz
- Electrical Connection:
- terminal nut, line || lugs, load
- Eu Rohs Directive:
- Compliant
- Line Rated Current:
- 50-50 A
- [Uimp] Rated Impulse Withstand Voltage:
- 8 kV IEC 60947-2
- Net Weight:
- 2.2 kg
- Magnetic Hold Current:
- 400 A
- Rohs Exemption Information:
- Yes
- Environmental Disclosure:
- ENVPEP1311006EN
- Ip Degree Of Protection:
- front cover IP40 IEC 60529
- Product Certifications:
- UL || CSA || NOM
- Quality Labels:
- CE
- Color:
- Black
- Sustainable Offer Status:
- Green Premium product
- Awg Gauge:
- AWG 14...AWG 3/0 aluminium/copper terminal
- Suitability For Isolation:
- yes IEC 60947-2
- Pollution Degree:
- 3 IEC 60947-1
- Mounting Mode:
- unit mount lug)
- Mercury Free:
- Yes
- Standards:
- UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
- Number Of Slots:
- 2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
- Pvc Free:
- Yes
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
- Wire Stripping Length:
- 16 mm
- Product Or Component Type:
- circuit breaker
- Breaking Capacity:
- 25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC
- Continuous Current Rating:
- 0.8
- Utilisation Category:
- category A
- Mounting Support:
- lug
- Depth:
- 86 mm
- Trip Unit Technology:
- thermal-magnetic
- Local Signalling:
- switched off (OFF) 1 trip indicator green)
- [Ui] Rated Insulation Voltage:
- 750 V IEC 60947-2
- Ambient Air Temperature For Operation:
- -2-70 °C
- Tightening Torque:
- 5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Height:
- 163 mm
- Breaking Capacity Code:
- D
- Circularity Profile:
- ENVEOLI1311006EN
- Quantity Per Set:
- 1
- Circuit Breaker Application:
- HACR rated
- Product Name:
- PowerPact H
- Range:
- PowerPact
- Warranty:
- 18 months
- Poles Description:
- 3P
- Terminal Identifier:
- AL150HD
