Schneider Electric HDP36125 Molded Case Circuit Breaker 600V 125A

Schneider Electric HDP36125 Molded Case Circuit Breaker 600V 125A

Schneider Electric
SKU:
HDP36125
|
UPC:
7.85902E+11
Availability:
Contact us to confirm availability and lead times.
$2,600.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has terminal nuts on the line side and lugs on the load side. This PowerPacT H, 125A, 3 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Eu Rohs Directive:
Compliant with Exemptions
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Ambient Air Temperature For Storage:
-50-85 °C
Network Frequency:
50/60 Hz
[Ics] Rated Service Breaking Capacity:
25 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Quantity Per Set:
1
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Quality Labels:
CE
Warranty:
18 months
Circularity Profile:
ENVEOLI2206027EN
Terminal Identifier:
AL150HD
Ip Degree Of Protection:
front cover IP40 IEC 60529
Wire Stripping Length:
16 mm
Mercury Free:
Yes
Continuous Current Rating:
0.8
Magnetic Hold Current:
900 A
Sustainable Offer Status:
Green Premium product
Height:
163 mm
Trip Unit Technology:
thermal-magnetic
Pollution Degree:
3 IEC 60947-1
Color:
Black
Mounting Support:
lug
Range:
PowerPact
Product Name:
PowerPact H
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Magnetic Tripping Current:
1700-1700 A
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Depth:
86 mm
Line Rated Current:
125-125 A
Electrical Connection:
terminal nut, line || lugs, load
Mounting Mode:
unit mount lug)
Net Weight:
2.2 kg
Control Type:
toggle
Communication Interface:
Modbus || Ethernet
Protected Poles Description:
3t
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Local Signalling:
switched off (OFF) 1 trip indicator green)
Rohs Exemption Information:
Yes
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Device Application:
distribution
Suitability For Isolation:
yes IEC 60947-2
Breaking Capacity:
25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC
Utilisation Category:
category A
Circuit Breaker Application:
HACR rated
Product Or Component Type:
circuit breaker
Pvc Free:
Yes
Breaking Capacity Code:
D
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Width:
104 mm
Ambient Air Temperature For Operation:
-2-70 °C
Environmental Disclosure:
ENVPEP2206027EN
Product Certifications:
UL || CSA || NOM
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Poles Description:
3P
