Schneider Electric HGA260206 Molded Case Circuit Breaker 600V 20A

Schneider Electric HGA260206 Molded Case Circuit Breaker 600V 20A

Schneider Electric
SKU:
HGA260206
|
UPC:
7.85901E+11
Availability:
Contact us to confirm availability and lead times.
$2,007.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 18kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. PowerPacT H I-Line circuit breakers are available in I-Line construction for easy installation and removal in I-Line applications. This breaker has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT H, 20A, 2 pole, circuit breaker has a breaking capacity of 18kA at 600VAC. This circuit breaker has a continuous current rating of 80% with a CB phase connection. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Magnetic Hold Current:
350 A
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Network Frequency:
50/60 Hz
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Communication Interface:
Modbus || Ethernet
Terminal Identifier:
AL150HD
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Warranty:
18 months
Product Name:
PowerPact H
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
[Ics] Rated Service Breaking Capacity:
65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Electrical Connection:
I-Line connection, line || lugs, load
Trip Unit Technology:
thermal-magnetic
Utilisation Category:
category A
Pollution Degree:
3 IEC 60947-1
Quantity Per Set:
1
Breaking Capacity:
65 kA 240 V AC 50/60 Hz UL 489 || 35 kA 480 V AC 50/60 Hz UL 489 || 18 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 20 kA 500 V DC UL 489
Control Type:
toggle
Mounting Mode:
I-Line bracket)
Protected Poles Description:
2t
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Height:
163 mm
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Pvc Free:
Yes
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Rohs Exemption Information:
Yes
Eu Rohs Directive:
Compliant with Exemptions
Ambient Air Temperature For Operation:
-2-70 °C
Continuous Current Rating:
0.8
Width:
104 mm
Wire Stripping Length:
16 mm
Product Certifications:
UL || CSA || NOM
Line Rated Current:
20-20 A
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Mercury Free:
Yes
Breaking Capacity Code:
G
Sustainable Offer Status:
Green Premium product
Device Application:
distribution
Mounting Height:
3 in
Suitability For Isolation:
yes IEC 60947-2
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Ambient Air Temperature For Storage:
-50-85 °C
Depth:
86 mm
Circuit Breaker Application:
HACR rated
Range:
PowerPact
Net Weight:
2.2 kg
Environmental Disclosure:
ENVPEP2206027EN
Magnetic Tripping Current:
750-750 A
Quality Labels:
CE
Ip Degree Of Protection:
front cover IP40 IEC 60529
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Poles Description:
2P
Circularity Profile:
ENVEOLI2206027EN
Product Or Component Type:
circuit breaker
Color:
Black
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Mounting Support:
bracket
Local Signalling:
switched off (OFF) 1 trip indicator green)
Phase Connection:
CB
