Schneider Electric HGA260302 Molded Case Circuit Breaker 600V 30A

Schneider Electric HGA260302 Molded Case Circuit Breaker 600V 30A

Schneider Electric
SKU:
HGA260302
|
UPC:
785901834274
Availability:
Contact us to confirm availability and lead times.
$1,338.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 18kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. PowerPacT H I-Line circuit breakers are available in I-Line construction for easy installation and removal in I-Line applications. This breaker has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT H, 30A, 2 pole, circuit breaker has a breaking capacity of 18kA at 600VAC. This circuit breaker has a continuous current rating of 80% with an AC phase connection. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Magnetic Tripping Current:
750-750 A
Ip Degree Of Protection:
front cover IP40 IEC 60529
Poles Description:
2P
Continuous Current Rating:
0.8
Line Rated Current:
30-30 A
Color:
Black
Protected Poles Description:
2t
Network Frequency:
50/60 Hz
Width:
104 mm
Mercury Free:
Yes
Device Application:
distribution
Sustainable Offer Status:
Green Premium product
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Warranty:
18 months
Utilisation Category:
category A
Communication Interface:
Modbus || Ethernet
Quality Labels:
CE
Circuit Breaker Application:
HACR rated
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Local Signalling:
switched off (OFF) 1 trip indicator green)
Height:
163 mm
Pollution Degree:
3 IEC 60947-1
Control Type:
toggle
Phase Connection:
AC
Wire Stripping Length:
16 mm
Product Or Component Type:
circuit breaker
Product Name:
PowerPact H
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Circularity Profile:
ENVEOLI2206027EN
Depth:
86 mm
Electrical Connection:
I-Line connection, line || lugs, load
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Terminal Identifier:
AL150HD
Magnetic Hold Current:
350 A
Trip Unit Technology:
thermal-magnetic
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Ambient Air Temperature For Operation:
-2-70 °C
Pvc Free:
Yes
Breaking Capacity Code:
G
Mounting Height:
3 in
Rohs Exemption Information:
Yes
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Environmental Disclosure:
ENVPEP2206027EN
Quantity Per Set:
1
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Product Certifications:
UL || CSA || NOM
Ambient Air Temperature For Storage:
-50-85 °C
Net Weight:
2.2 kg
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Suitability For Isolation:
yes IEC 60947-2
Mounting Mode:
I-Line bracket)
[Ics] Rated Service Breaking Capacity:
65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Eu Rohs Directive:
Compliant with Exemptions
Range:
PowerPact
Breaking Capacity:
65 kA 240 V AC 50/60 Hz UL 489 || 35 kA 480 V AC 50/60 Hz UL 489 || 18 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 20 kA 500 V DC UL 489
Mounting Support:
bracket
