Schneider Electric HGA260601 Molded Case Circuit Breaker 600V 60A

Schneider Electric HGA260601 Molded Case Circuit Breaker 600V 60A

Schneider Electric
SKU:
HGA260601
|
UPC:
785901539827
Availability:
Factory stock
$1,279.16
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 18kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. PowerPacT H I-Line circuit breakers are available in I-Line construction for easy installation and removal in I-Line applications. This breaker has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT H, 60A, 2 pole, circuit breaker has a breaking capacity of 18kA at 600VAC. This circuit breaker has a continuous current rating of 80% with an AB phase connection. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Mounting Height:
3 in
Ambient Air Temperature For Operation:
-2-70 °C
Mounting Support:
bracket
Poles Description:
2P
Ambient Air Temperature For Storage:
-50-85 °C
Mercury Free:
Yes
Net Weight:
2.2 kg
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Network Frequency:
50/60 Hz
Range:
PowerPact
Environmental Disclosure:
ENVPEP1311006EN
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Rohs Exemption Information:
Yes
Line Rated Current:
60-60 A
Quality Labels:
CE
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Width:
104 mm
Magnetic Hold Current:
800 A
Quantity Per Set:
1
Height:
163 mm
Device Application:
distribution
Color:
Black
Control Type:
toggle
Pvc Free:
Yes
Breaking Capacity Code:
G
Trip Unit Technology:
thermal-magnetic
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Phase Connection:
AB
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Circuit Breaker Application:
HACR rated
Electrical Connection:
I-Line connection, line || lugs, load
Magnetic Tripping Current:
1450-1450 A
Eu Rohs Directive:
Compliant
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Product Or Component Type:
circuit breaker
Depth:
86 mm
Product Name:
PowerPact H
Ip Degree Of Protection:
front cover IP40 IEC 60529
Sustainable Offer Status:
Green Premium product
[Ics] Rated Service Breaking Capacity:
65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Utilisation Category:
category A
Breaking Capacity:
65 kA 240 V AC 50/60 Hz UL 489 || 35 kA 480 V AC 50/60 Hz UL 489 || 18 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 20 kA 500 V DC UL 489
Product Certifications:
UL || CSA || NOM
Circularity Profile:
ENVEOLI1311006EN
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Local Signalling:
switched off (OFF) 1 trip indicator green)
Pollution Degree:
3 IEC 60947-1
Protected Poles Description:
2t
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Communication Interface:
Modbus || Ethernet
Suitability For Isolation:
yes IEC 60947-2
Warranty:
18 months
Terminal Identifier:
AL150HD
Mounting Mode:
I-Line bracket)
Wire Stripping Length:
16 mm
Continuous Current Rating:
0.8
