Schneider Electric HGA261251 Molded Case Circuit Breaker 600V 125A

Schneider Electric HGA261251 Molded Case Circuit Breaker 600V 125A

Schneider Electric
SKU:
HGA261251
|
UPC:
7.85902E+11
Availability:
Contact us to confirm availability and lead times.
$3,212.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 18kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. PowerPacT H I-Line circuit breakers are available in I-Line construction for easy installation and removal in I-Line applications. This breaker has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT H, 125A, 2 pole, circuit breaker has a breaking capacity of 18kA at 600VAC. This circuit breaker has a continuous current rating of 80% with an AB phase connection. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Net Weight:
2.2 kg
Phase Connection:
AB
Wire Stripping Length:
16 mm
Magnetic Hold Current:
900 A
Quantity Per Set:
1
Product Name:
PowerPact H
Electrical Connection:
I-Line connection, line || lugs, load
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Utilisation Category:
category A
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Mounting Mode:
I-Line bracket)
Depth:
86 mm
Color:
Black
Protected Poles Description:
2t
Rohs Exemption Information:
Yes
Terminal Identifier:
AL150HD
Mounting Height:
3 in
Circuit Breaker Application:
HACR rated
Quality Labels:
CE
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Circularity Profile:
ENVEOLI2206027EN
Ambient Air Temperature For Operation:
-2-70 °C
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Range:
PowerPact
Pollution Degree:
3 IEC 60947-1
Breaking Capacity Code:
G
Device Application:
distribution
Trip Unit Technology:
thermal-magnetic
Suitability For Isolation:
yes IEC 60947-2
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Product Certifications:
UL || CSA || NOM
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Eu Rohs Directive:
Compliant with Exemptions
Height:
163 mm
Ambient Air Temperature For Storage:
-50-85 °C
Sustainable Offer Status:
Green Premium product
Breaking Capacity:
65 kA 240 V AC 50/60 Hz UL 489 || 35 kA 480 V AC 50/60 Hz UL 489 || 18 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 20 kA 500 V DC UL 489
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Environmental Disclosure:
ENVPEP2206027EN
[Ics] Rated Service Breaking Capacity:
65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Communication Interface:
Modbus || Ethernet
Local Signalling:
switched off (OFF) 1 trip indicator green)
Poles Description:
2P
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Product Or Component Type:
circuit breaker
Control Type:
toggle
Network Frequency:
50/60 Hz
Mercury Free:
Yes
Line Rated Current:
125-125 A
Warranty:
18 months
Width:
104 mm
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Continuous Current Rating:
0.8
Ip Degree Of Protection:
front cover IP40 IEC 60529
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Pvc Free:
Yes
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Magnetic Tripping Current:
1700-1700 A
Mounting Support:
bracket
