Schneider Electric HGF36100 Molded Case Circuit Breaker 600V 100A

Schneider Electric HGF36100 Molded Case Circuit Breaker 600V 100A

Schneider Electric
SKU:
HGF36100
|
UPC:
7.85902E+11
Availability:
Factory stock
$1,084.14
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 18kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has a busbar connection. This PowerPacT H, 100A, 3 pole, circuit breaker has a breaking capacity of 18kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Breaking Capacity Code:
G
Mounting Mode:
unit mount busbar)
Net Weight:
2.2 kg
Warranty:
18 months
Circuit Breaker Application:
HACR rated
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Local Signalling:
switched off (OFF) 1 trip indicator green)
Device Application:
distribution
Ip Degree Of Protection:
front cover IP40 IEC 60529
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Poles Description:
3P
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Control Type:
toggle
Magnetic Hold Current:
900 A
Trip Unit Technology:
thermal-magnetic
Suitability For Isolation:
yes IEC 60947-2
Breaking Capacity:
65 kA 240 V AC 50/60 Hz UL 489 || 35 kA 480 V AC 50/60 Hz UL 489 || 18 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 20 kA 500 V DC UL 489
Mercury Free:
Yes
Magnetic Tripping Current:
1700-1700 A
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Mounting Support:
busbar
Ambient Air Temperature For Operation:
-2-70 °C
Range:
PowerPact
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Product Name:
PowerPact H
Network Frequency:
50/60 Hz
Communication Interface:
Modbus || Ethernet
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Environmental Disclosure:
ENVPEP2206027EN
Color:
Black
Pollution Degree:
3 IEC 60947-1
Protected Poles Description:
3t
Electrical Connection:
busbar connection, line || busbar connection, load
Terminal Identifier:
AL150HD
Product Certifications:
UL || CSA || NOM
Product Or Component Type:
circuit breaker
Quality Labels:
CE
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Ambient Air Temperature For Storage:
-50-85 °C
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Circularity Profile:
ENVEOLI2206027EN
Width:
104 mm
Eu Rohs Directive:
Compliant with Exemptions
Rohs Exemption Information:
Yes
Pvc Free:
Yes
Quantity Per Set:
1
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Height:
163 mm
Continuous Current Rating:
0.8
[Ics] Rated Service Breaking Capacity:
65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Wire Stripping Length:
16 mm
Utilisation Category:
category A
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Depth:
86 mm
Line Rated Current:
100-100 A
Sustainable Offer Status:
Green Premium product
