Schneider Electric HGL26035 Molded Case Circuit Breaker 600V 35A
Schneider Electric
$1,269.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 18kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 35A, 2 pole, circuit breaker has a breaking capacity of 18kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
- Width:
- 104 mm
- Color:
- Black
- Circuit Breaker Application:
- HACR rated
- [Uimp] Rated Impulse Withstand Voltage:
- 8 kV IEC 60947-2
- Mercury Free:
- Yes
- [Ue] Rated Operational Voltage:
- 690 V AC 50/60 Hz IEC 60947-3
- Operating Altitude:
- < 6561.68 ft (2000 m) without derating || 5000 m with derating
- Magnetic Tripping Current:
- 850-850 A
- Warranty:
- 18 months
- Product Certifications:
- UL || CSA || NOM
- Network Frequency:
- 50/60 Hz
- Pollution Degree:
- 3 IEC 60947-1
- Standards:
- UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
- Ambient Air Temperature For Operation:
- -2-70 °C
- Quantity Per Set:
- 1
- Utilisation Category:
- category A
- Terminal Identifier:
- AL150HD
- [Ics] Rated Service Breaking Capacity:
- 65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
- Quality Labels:
- CE
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Suitability For Isolation:
- yes IEC 60947-2
- Rohs Exemption Information:
- Yes
- Environmental Disclosure:
- ENVPEP2206027EN
- Breaking Capacity Code:
- G
- Sustainable Offer Status:
- Green Premium product
- Range:
- PowerPact
- Protected Poles Description:
- 2t
- Mounting Mode:
- unit mount lug)
- Eu Rohs Directive:
- Compliant with Exemptions
- Awg Gauge:
- AWG 14...AWG 3/0 aluminium/copper terminal
- Ambient Air Temperature For Storage:
- -50-85 °C
- Pvc Free:
- Yes
- [Ui] Rated Insulation Voltage:
- 750 V IEC 60947-2
- Tightening Torque:
- 5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
- Device Application:
- distribution
- Mounting Support:
- lug
- Number Of Slots:
- 2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
- Height:
- 163 mm
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Magnetic Hold Current:
- 400 A
- Net Weight:
- 2.2 kg
- Wire Stripping Length:
- 16 mm
- Trip Unit Technology:
- thermal-magnetic
- Product Or Component Type:
- circuit breaker
- Communication Interface:
- Modbus || Ethernet
- Continuous Current Rating:
- 0.8
- Circularity Profile:
- ENVEOLI2206027EN
- Line Rated Current:
- 35-35 A
- Ip Degree Of Protection:
- front cover IP40 IEC 60529
- Product Name:
- PowerPact H
- Local Signalling:
- switched off (OFF) 1 trip indicator green)
- Depth:
- 86 mm
- Breaking Capacity:
- 65 kA 240 V AC 50/60 Hz UL 489 || 35 kA 480 V AC 50/60 Hz UL 489 || 18 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 20 kA 500 V DC UL 489
- Poles Description:
- 2P
- Control Type:
- toggle
- Electrical Connection:
- lugs, line || lugs, load
