Schneider Electric HGL26125 Molded Case Circuit Breaker 600V 125A

Schneider Electric HGL26125 Molded Case Circuit Breaker 600V 125A

Schneider Electric
SKU:
HGL26125
|
UPC:
785901598848
Availability:
Factory stock
$1,949.65
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 18kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 125A, 2 pole, circuit breaker has a breaking capacity of 18kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Magnetic Tripping Current:
1700-1700 A
Mercury Free:
Yes
Mounting Mode:
unit mount lug)
Ambient Air Temperature For Storage:
-50-85 °C
Quality Labels:
CE
Poles Description:
2P
Local Signalling:
switched off (OFF) 1 trip indicator green)
Mounting Support:
lug
Product Or Component Type:
circuit breaker
Product Name:
PowerPact H
Suitability For Isolation:
yes IEC 60947-2
Control Type:
toggle
Width:
104 mm
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Electrical Connection:
lugs, line || lugs, load
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Height:
163 mm
Protected Poles Description:
2t
Breaking Capacity Code:
G
Ip Degree Of Protection:
front cover IP40 IEC 60529
Pvc Free:
Yes
Line Rated Current:
125-125 A
Range:
PowerPact
Ambient Air Temperature For Operation:
-2-70 °C
[Ics] Rated Service Breaking Capacity:
65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Quantity Per Set:
1
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Eu Rohs Directive:
Compliant with Exemptions
Magnetic Hold Current:
900 A
Terminal Identifier:
AL150HD
Circuit Breaker Application:
HACR rated
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Depth:
86 mm
Circularity Profile:
ENVEOLI2206027EN
Trip Unit Technology:
thermal-magnetic
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Pollution Degree:
3 IEC 60947-1
Product Certifications:
UL || CSA || NOM
Environmental Disclosure:
ENVPEP2206027EN
Continuous Current Rating:
0.8
Device Application:
distribution
Breaking Capacity:
65 kA 240 V AC 50/60 Hz UL 489 || 35 kA 480 V AC 50/60 Hz UL 489 || 18 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 20 kA 500 V DC UL 489
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Utilisation Category:
category A
Wire Stripping Length:
16 mm
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Net Weight:
2.2 kg
Warranty:
18 months
Sustainable Offer Status:
Green Premium product
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Color:
Black
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Communication Interface:
Modbus || Ethernet
Network Frequency:
50/60 Hz
Rohs Exemption Information:
Yes
