Schneider Electric HGL36025C Molded Case Circuit Breaker 600V 25A
Schneider Electric
$2,686.50
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric HGL36025C Molded Case Circuit Breaker 600V 25A
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 18kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 25A, 3 pole, circuit breaker has a breaking capacity of 18kA at 600VAC. This circuit breaker has a continuous current rating of 100%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
- Sustainable Offer Status:
- Green Premium product
- Height:
- 163 mm
- [Ui] Rated Insulation Voltage:
- 750 V IEC 60947-2
- Depth:
- 86 mm
- Suitability For Isolation:
- yes IEC 60947-2
- Network Frequency:
- 50/60 Hz
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Rohs Exemption Information:
- Yes
- Breaking Capacity Code:
- G
- Continuous Current Rating:
- 1
- Magnetic Hold Current:
- 350 A
- Poles Description:
- 3P
- Utilisation Category:
- category A
- Quality Labels:
- CE
- Environmental Disclosure:
- ENVPEP2206027EN
- Circularity Profile:
- ENVEOLI2206027EN
- Quantity Per Set:
- 1
- Local Signalling:
- switched off (OFF) 1 trip indicator green)
- Standards:
- UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
- Eu Rohs Directive:
- Compliant with Exemptions
- Product Name:
- PowerPact H
- Terminal Identifier:
- AL150HD
- Range:
- PowerPact
- Awg Gauge:
- AWG 14...AWG 3/0 aluminium/copper terminal
- Net Weight:
- 2.2 kg
- [Ue] Rated Operational Voltage:
- 690 V AC 50/60 Hz IEC 60947-3
- Mercury Free:
- Yes
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
- Control Type:
- toggle
- Ambient Air Temperature For Storage:
- -50-85 °C
- Width:
- 104 mm
- Product Or Component Type:
- circuit breaker
- Circuit Breaker Application:
- HACR rated
- Wire Stripping Length:
- 16 mm
- Trip Unit Technology:
- thermal-magnetic
- Product Certifications:
- UL || CSA || NOM
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Device Application:
- distribution
- Ambient Air Temperature For Operation:
- -2-70 °C
- [Uimp] Rated Impulse Withstand Voltage:
- 8 kV IEC 60947-2
- Mounting Mode:
- unit mount lug)
- Communication Interface:
- Modbus || Ethernet
- Pvc Free:
- Yes
- Magnetic Tripping Current:
- 750-750 A
- Pollution Degree:
- 3 IEC 60947-1
- Tightening Torque:
- 5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
- Number Of Slots:
- 2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
- Warranty:
- 18 months
- Ip Degree Of Protection:
- front cover IP40 IEC 60529
- Mounting Support:
- lug
- Breaking Capacity:
- 65 kA 240 V AC 50/60 Hz UL 489 || 35 kA 480 V AC 50/60 Hz UL 489 || 18 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 20 kA 500 V DC UL 489
- Line Rated Current:
- 25-25 A
- Color:
- Black
- Electrical Connection:
- lugs, line || lugs, load
- [Ics] Rated Service Breaking Capacity:
- 65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
- Protected Poles Description:
- 3t
- Operating Altitude:
- < 6561.68 ft (2000 m) without derating || 5000 m with derating
