Schneider Electric HGP36020 Molded Case Circuit Breaker 600V 20A

(No reviews yet) Write a Review

Write a Review

Schneider Electric HGP36020 Molded Case Circuit Breaker 600V 20A

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

HGP36020

UPC:

785901825098

MPN:

Condition:

New

Line Rated Current:

20-20 A

Environmental Disclosure:

ENVPEP2206027EN

Trip Unit Technology:

thermal-magnetic

Circularity Profile:

ENVEOLI2206027EN

Rohs Exemption Information:

Yes

Product Certifications:

UL || CSA || NOM

Warranty:

18 months

California Proposition 65:

WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information

Utilisation Category:

category A

Ip Degree Of Protection:

front cover IP40 IEC 60529

Quantity Per Set:

1

Pollution Degree:

3 IEC 60947-1

Local Signalling:

switched off (OFF) 1 trip indicator green)

Tightening Torque:

5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)

Circuit Breaker Application:

HACR rated

Magnetic Hold Current:

350 A

Electrical Connection:

terminal nut, line || lugs, load

Communication Interface:

Modbus || Ethernet

[Ui] Rated Insulation Voltage:

750 V IEC 60947-2

Terminal Identifier:

AL150HD

Ambient Air Temperature For Storage:

-50-85 °C

Suitability For Isolation:

yes IEC 60947-2

[Ics] Rated Service Breaking Capacity:

65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2

Mounting Support:

lug

Product Or Component Type:

circuit breaker

Mounting Mode:

unit mount lug)

Standards:

UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2

Net Weight:

2.2 kg

Awg Gauge:

AWG 14...AWG 3/0 aluminium/copper terminal

Device Application:

distribution

Product Name:

PowerPact H

Operating Altitude:

< 6561.68 ft (2000 m) without derating || 5000 m with derating

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Ambient Air Temperature For Operation:

-2-70 °C

Color:

Black

Number Of Slots:

2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)

Control Type:

toggle

Breaking Capacity:

65 kA 240 V AC 50/60 Hz UL 489 || 35 kA 480 V AC 50/60 Hz UL 489 || 18 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 20 kA 500 V DC UL 489

[Uimp] Rated Impulse Withstand Voltage:

8 kV IEC 60947-2

Continuous Current Rating:

0.8

Protected Poles Description:

3t

Eu Rohs Directive:

Compliant with Exemptions

Pvc Free:

Yes

Breaking Capacity Code:

G

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Quality Labels:

CE

Width:

104 mm

Mercury Free:

Yes

Network Frequency:

50/60 Hz

Sustainable Offer Status:

Green Premium product

Wire Stripping Length:

16 mm

Range:

PowerPact

Depth:

86 mm

Magnetic Tripping Current:

750-750 A

Poles Description:

3P

[Ue] Rated Operational Voltage:

690 V AC 50/60 Hz IEC 60947-3

Height:

163 mm
