Schneider Electric HGP36050 Molded Case Circuit Breaker 600V 50A

Schneider Electric HGP36050 Molded Case Circuit Breaker 600V 50A

Schneider Electric
SKU:
HGP36050
|
UPC:
785901551065
Availability:
Contact us to confirm availability and lead times.
$1,493.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 18kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has terminal nuts on the line side and lugs on the load side. This PowerPacT H, 50A, 3 pole, circuit breaker has a breaking capacity of 18kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Eu Rohs Directive:
Compliant with Exemptions
Breaking Capacity Code:
G
Suitability For Isolation:
yes IEC 60947-2
Ambient Air Temperature For Storage:
-50-85 °C
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Terminal Identifier:
AL150HD
Circularity Profile:
ENVEOLI2206027EN
Environmental Disclosure:
ENVPEP2206027EN
Ip Degree Of Protection:
front cover IP40 IEC 60529
Protected Poles Description:
3t
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Sustainable Offer Status:
Green Premium product
Range:
PowerPact
Utilisation Category:
category A
Depth:
86 mm
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Electrical Connection:
terminal nut, line || lugs, load
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
[Ics] Rated Service Breaking Capacity:
65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Ambient Air Temperature For Operation:
-2-70 °C
Warranty:
18 months
Width:
104 mm
Color:
Black
Quantity Per Set:
1
Mounting Mode:
unit mount lug)
Pvc Free:
Yes
Net Weight:
2.2 kg
Quality Labels:
CE
Product Name:
PowerPact H
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Height:
163 mm
Network Frequency:
50/60 Hz
Circuit Breaker Application:
HACR rated
Magnetic Hold Current:
400 A
Rohs Exemption Information:
Yes
Pollution Degree:
3 IEC 60947-1
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Wire Stripping Length:
16 mm
Poles Description:
3P
Trip Unit Technology:
thermal-magnetic
Continuous Current Rating:
0.8
Mercury Free:
Yes
Device Application:
distribution
Communication Interface:
Modbus || Ethernet
Product Certifications:
UL || CSA || NOM
Breaking Capacity:
65 kA 240 V AC 50/60 Hz UL 489 || 35 kA 480 V AC 50/60 Hz UL 489 || 18 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 20 kA 500 V DC UL 489
Magnetic Tripping Current:
850-850 A
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Line Rated Current:
50-50 A
Product Or Component Type:
circuit breaker
Mounting Support:
lug
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Local Signalling:
switched off (OFF) 1 trip indicator green)
Control Type:
toggle
