Schneider Electric HJA260501 Molded Case Circuit Breaker 600V 50A

(No reviews yet) Write a Review

Write a Review

Schneider Electric HJA260501 Molded Case Circuit Breaker 600V 50A

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

HJA260501

UPC:

785901540014

MPN:

Condition:

New

Eu Rohs Directive:

Compliant

[Ui] Rated Insulation Voltage:

750 V IEC 60947-2

Mounting Height:

4.5 in

Quality Labels:

CE

Ip Degree Of Protection:

front cover IP40 IEC 60529

Environmental Disclosure:

ENVPEP1311006EN

Circularity Profile:

ENVEOLI1311006EN

Rohs Exemption Information:

Yes

Local Signalling:

switched off (OFF) 1 trip indicator green)

Ambient Air Temperature For Storage:

-50-85 °C

Warranty:

18 months

Control Type:

toggle

Sustainable Offer Status:

Green Premium product

Trip Unit Technology:

thermal-magnetic

Tightening Torque:

5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)

Phase Connection:

AB

Height:

163 mm

Standards:

UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2

Number Of Slots:

2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)

Wire Stripping Length:

16 mm

Continuous Current Rating:

0.8

Suitability For Isolation:

yes IEC 60947-2

Line Rated Current:

50-50 A

Communication Interface:

Modbus || Ethernet

Magnetic Hold Current:

400 A

Breaking Capacity:

100 kA 240 V AC 50/60 Hz UL 489 || 65 kA 480 V AC 50/60 Hz UL 489 || 25 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489

[Ics] Rated Service Breaking Capacity:

100 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 65 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 25 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2

Network Frequency:

50/60 Hz

Mounting Mode:

I-Line bracket)

Electrical Connection:

I-Line connection, line || lugs, load

Product Or Component Type:

circuit breaker

California Proposition 65:

WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information

Terminal Identifier:

AL150HD

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

[Uimp] Rated Impulse Withstand Voltage:

8 kV IEC 60947-2

Mercury Free:

Yes

Depth:

86 mm

[Ue] Rated Operational Voltage:

690 V AC 50/60 Hz IEC 60947-3

Device Application:

distribution

Protected Poles Description:

2t

Product Name:

PowerPact H

Net Weight:

2.2 kg

Circuit Breaker Application:

HACR rated

Ambient Air Temperature For Operation:

-2-70 °C

Mounting Support:

bracket

Product Certifications:

UL || CSA || NOM

Poles Description:

2P

Pollution Degree:

3 IEC 60947-1

Width:

104 mm

Quantity Per Set:

1

Breaking Capacity Code:

J

Utilisation Category:

category A

Pvc Free:

Yes

Awg Gauge:

AWG 14...AWG 3/0 aluminium/copper terminal

Magnetic Tripping Current:

850-850 A

Range:

PowerPact

Operating Altitude:

< 6561.68 ft (2000 m) without derating || 5000 m with derating

Color:

Black
