Schneider Electric HJA260801 Molded Case Circuit Breaker 600V 80A

Schneider Electric HJA260801 Molded Case Circuit Breaker 600V 80A

Schneider Electric
SKU:
HJA260801
|
UPC:
7.85902E+11
Availability:
Contact us to confirm availability and lead times.
$4,104.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 25kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. PowerPacT H I-Line circuit breakers are available in I-Line construction for easy installation and removal in I-Line applications. This breaker has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT H, 80A, 2 pole, circuit breaker has a breaking capacity of 25kA at 600VAC. This circuit breaker has a continuous current rating of 80% with an AB phase connection. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Circuit Breaker Application:
HACR rated
Continuous Current Rating:
0.8
Warranty:
18 months
Suitability For Isolation:
yes IEC 60947-2
Mounting Mode:
I-Line bracket)
Ip Degree Of Protection:
front cover IP40 IEC 60529
Ambient Air Temperature For Operation:
-2-70 °C
Rohs Exemption Information:
Yes
Color:
Black
Phase Connection:
AB
Width:
104 mm
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Net Weight:
2.2 kg
Mounting Support:
bracket
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Product Certifications:
UL || CSA || NOM
Device Application:
distribution
Electrical Connection:
I-Line connection, line || lugs, load
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Mercury Free:
Yes
Line Rated Current:
80-80 A
Magnetic Tripping Current:
1450-1450 A
Pollution Degree:
3 IEC 60947-1
Communication Interface:
Modbus || Ethernet
Network Frequency:
50/60 Hz
Environmental Disclosure:
ENVPEP1311006EN
Pvc Free:
Yes
Product Or Component Type:
circuit breaker
Quantity Per Set:
1
Depth:
86 mm
[Ics] Rated Service Breaking Capacity:
100 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 65 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 25 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Eu Rohs Directive:
Compliant
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Circularity Profile:
ENVEOLI1311006EN
Poles Description:
2P
Range:
PowerPact
Protected Poles Description:
2t
Height:
163 mm
Breaking Capacity Code:
J
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Magnetic Hold Current:
800 A
Utilisation Category:
category A
Product Name:
PowerPact H
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Quality Labels:
CE
Terminal Identifier:
AL150HD
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Mounting Height:
4.5 in
Trip Unit Technology:
thermal-magnetic
Breaking Capacity:
100 kA 240 V AC 50/60 Hz UL 489 || 65 kA 480 V AC 50/60 Hz UL 489 || 25 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489
Control Type:
toggle
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Local Signalling:
switched off (OFF) 1 trip indicator green)
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Ambient Air Temperature For Storage:
-50-85 °C
Sustainable Offer Status:
Green Premium product
Wire Stripping Length:
16 mm
