Schneider Electric HJF36040 Molded Case Circuit Breaker 600V 40A

Schneider Electric HJF36040 Molded Case Circuit Breaker 600V 40A

Schneider Electric
SKU:
HJF36040
|
UPC:
3.60648E+12
Availability:
Factory stock
$2,662.18
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 25kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has a busbar connection. This PowerPacT H, 40A, 3 pole, circuit breaker has a breaking capacity of 25kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Sustainable Offer Status:
Green Premium product
Circuit Breaker Application:
HACR rated
Electrical Connection:
busbar connection, line || busbar connection, load
Poles Description:
3P
Magnetic Hold Current:
400 A
Height:
163 mm
Network Frequency:
50/60 Hz
[Ics] Rated Service Breaking Capacity:
100 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 65 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 25 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Line Rated Current:
40-40 A
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Ambient Air Temperature For Operation:
-2-70 °C
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Depth:
86 mm
Width:
104 mm
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Suitability For Isolation:
yes IEC 60947-2
Product Or Component Type:
circuit breaker
Product Name:
PowerPact H
Mounting Mode:
unit mount busbar)
Trip Unit Technology:
thermal-magnetic
Environmental Disclosure:
ENVPEP2206027EN
Wire Stripping Length:
16 mm
Circularity Profile:
ENVEOLI2206027EN
Magnetic Tripping Current:
850-850 A
Pollution Degree:
3 IEC 60947-1
Net Weight:
2.2 kg
Breaking Capacity Code:
J
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Warranty:
18 months
Continuous Current Rating:
0.8
Pvc Free:
Yes
Breaking Capacity:
100 kA 240 V AC 50/60 Hz UL 489 || 65 kA 480 V AC 50/60 Hz UL 489 || 25 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489
Terminal Identifier:
AL150HD
Utilisation Category:
category A
Ip Degree Of Protection:
front cover IP40 IEC 60529
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Protected Poles Description:
3t
Quantity Per Set:
1
Rohs Exemption Information:
Yes
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Product Certifications:
UL || CSA || NOM
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Mounting Support:
busbar
Color:
Black
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Communication Interface:
Modbus || Ethernet
Local Signalling:
switched off (OFF) 1 trip indicator green)
Mercury Free:
Yes
Eu Rohs Directive:
Compliant with Exemptions
Ambient Air Temperature For Storage:
-50-85 °C
Quality Labels:
CE
Device Application:
distribution
Range:
PowerPact
Control Type:
toggle
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
