Schneider Electric HJL36090AA Molded Case Circuit Breaker 600V 90A

Schneider Electric HJL36090AA Molded Case Circuit Breaker 600V 90A

Schneider Electric
SKU:
HJL36090AA
|
UPC:
785901567103
Availability:
Factory stock
$1,454.55
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 25kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 90A, 3 pole, circuit breaker has a breaking capacity of 25kA at 600VAC. This circuit breaker has a continuous current rating of 80%. This unit includes a factory installed 1A/1B auxiliary switch. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Breaking Capacity:
100 kA 240 V AC 50/60 Hz UL 489 || 65 kA 480 V AC 50/60 Hz UL 489 || 25 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489
Mounting Mode:
unit mount lug)
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Environmental Disclosure:
ENVPEP2206027EN
Wire Stripping Length:
16 mm
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Ambient Air Temperature For Operation:
-2-70 °C
Utilisation Category:
category A
Color:
Black
Suitability For Isolation:
yes IEC 60947-2
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Mercury Free:
Yes
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Circuit Breaker Application:
HACR rated
Terminal Identifier:
AL150HD
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Pvc Free:
Yes
Product Name:
PowerPact H
Pollution Degree:
3 IEC 60947-1
Width:
104 mm
Network Frequency:
50/60 Hz
Breaking Capacity Code:
J
Warranty:
18 months
Product Certifications:
UL || CSA || NOM
Quantity Per Set:
1
Net Weight:
2.2 kg
Product Or Component Type:
circuit breaker
Electrical Connection:
lugs, line || lugs, load
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Sustainable Offer Status:
Green Premium product
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Eu Rohs Directive:
Compliant with Exemptions
Protected Poles Description:
3t
Continuous Current Rating:
0.8
Rohs Exemption Information:
Yes
Range:
PowerPact
Ambient Air Temperature For Storage:
-50-85 °C
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Magnetic Tripping Current:
1450-1450 A
Accessory / Separate Part Type:
auxiliary switch 24 V AC/DC 1 NO + 1 NC cover frame
Trip Unit Technology:
thermal-magnetic
Depth:
86 mm
Magnetic Hold Current:
800 A
Height:
163 mm
Line Rated Current:
90-90 A
[Ics] Rated Service Breaking Capacity:
65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Communication Interface:
Modbus || Ethernet
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Device Application:
distribution
Ip Degree Of Protection:
front cover IP40 IEC 60529
Mounting Support:
lug
Poles Description:
3P
Quality Labels:
CE
Circularity Profile:
ENVEOLI2206027EN
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Control Type:
toggle
Local Signalling:
switched off (OFF) 1 trip indicator green)
