Schneider Electric HJL36125C Molded Case Circuit Breaker 600V 125A

Schneider Electric HJL36125C Molded Case Circuit Breaker 600V 125A

Schneider Electric
SKU:
HJL36125C
|
UPC:
785901636656
Availability:
Factory stock
$3,957.30
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 25kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 125A, 3 pole, circuit breaker has a breaking capacity of 25kA at 600VAC. This circuit breaker has a continuous current rating of 100%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Electrical Connection:
lugs, line || lugs, load
Pollution Degree:
3 IEC 60947-1
Circularity Profile:
ENVEOLI2206027EN
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Environmental Disclosure:
ENVPEP2206027EN
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Utilisation Category:
category A
Ip Degree Of Protection:
front cover IP40 IEC 60529
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Warranty:
18 months
Local Signalling:
switched off (OFF) 1 trip indicator green)
Network Frequency:
50/60 Hz
Height:
163 mm
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Circuit Breaker Application:
HACR rated
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Pvc Free:
Yes
Depth:
86 mm
Product Certifications:
UL || CSA || NOM
Width:
104 mm
Ambient Air Temperature For Storage:
-50-85 °C
Breaking Capacity Code:
J
Wire Stripping Length:
16 mm
Product Or Component Type:
circuit breaker
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Sustainable Offer Status:
Green Premium product
Continuous Current Rating:
1
Magnetic Tripping Current:
1700-1700 A
Breaking Capacity:
100 kA 240 V AC 50/60 Hz UL 489 || 65 kA 480 V AC 50/60 Hz UL 489 || 25 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Color:
Black
Range:
PowerPact
Communication Interface:
Modbus || Ethernet
Line Rated Current:
125-125 A
Net Weight:
2.2 kg
Eu Rohs Directive:
Compliant with Exemptions
Terminal Identifier:
AL150HD
Control Type:
toggle
Mounting Mode:
unit mount lug)
Quantity Per Set:
1
Device Application:
distribution
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Protected Poles Description:
3t
Trip Unit Technology:
thermal-magnetic
Mercury Free:
Yes
Magnetic Hold Current:
900 A
Mounting Support:
lug
Suitability For Isolation:
yes IEC 60947-2
Rohs Exemption Information:
Yes
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Poles Description:
3P
Product Name:
PowerPact H
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Ambient Air Temperature For Operation:
-2-70 °C
[Ics] Rated Service Breaking Capacity:
65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Quality Labels:
CE
