Schneider Electric HJP36015 Molded Case Circuit Breaker 600V 15A

Schneider Electric HJP36015 Molded Case Circuit Breaker 600V 15A

Schneider Electric
SKU:
HJP36015
|
UPC:
785901085553
Availability:
Contact us to confirm availability and lead times.
$2,923.50
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 25kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has terminal nuts on the line side and lugs on the load side. This PowerPacT H, 15A, 3 pole, circuit breaker has a breaking capacity of 25kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Electrical Connection:
terminal nut, line || lugs, load
Utilisation Category:
category A
Product Or Component Type:
circuit breaker
Circuit Breaker Application:
HACR rated
[Ics] Rated Service Breaking Capacity:
65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Ambient Air Temperature For Operation:
-2-70 °C
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Breaking Capacity Code:
J
Range:
PowerPact
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Local Signalling:
switched off (OFF) 1 trip indicator green)
Control Type:
toggle
Height:
163 mm
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Ambient Air Temperature For Storage:
-50-85 °C
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Pvc Free:
Yes
Wire Stripping Length:
16 mm
Quality Labels:
CE
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Eu Rohs Directive:
Compliant with Exemptions
Mounting Mode:
unit mount lug)
Warranty:
18 months
Poles Description:
3P
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Terminal Identifier:
AL150HD
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Net Weight:
2.2 kg
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Color:
Black
Depth:
86 mm
Quantity Per Set:
1
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Continuous Current Rating:
0.8
Breaking Capacity:
100 kA 240 V AC 50/60 Hz UL 489 || 65 kA 480 V AC 50/60 Hz UL 489 || 25 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489
Protected Poles Description:
3t
Magnetic Tripping Current:
750-750 A
Mounting Support:
lug
Product Name:
PowerPact H
Pollution Degree:
3 IEC 60947-1
Line Rated Current:
15-15 A
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Network Frequency:
50/60 Hz
Circularity Profile:
ENVEOLI2206027EN
Mercury Free:
Yes
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Device Application:
distribution
Sustainable Offer Status:
Green Premium product
Trip Unit Technology:
thermal-magnetic
Communication Interface:
Modbus || Ethernet
Width:
104 mm
Product Certifications:
UL || CSA || NOM
Magnetic Hold Current:
350 A
Ip Degree Of Protection:
front cover IP40 IEC 60529
Suitability For Isolation:
yes IEC 60947-2
Rohs Exemption Information:
Yes
Environmental Disclosure:
ENVPEP2206027EN
