Schneider Electric HLA260154 Molded Case Circuit Breaker 600V 15A

Schneider Electric HLA260154 Molded Case Circuit Breaker 600V 15A

Schneider Electric
SKU:
HLA260154
|
UPC:
785901939283
Availability:
Contact us to confirm availability and lead times.
$3,724.50
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 50kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. PowerPacT H I-Line circuit breakers are available in I-Line construction for easy installation and removal in I-Line applications. This breaker has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT H, 15A, 2 pole, circuit breaker has a breaking capacity of 50kA at 600VAC. This circuit breaker has a continuous current rating of 80% with a BC phase connection. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Electrical Connection:
I-Line connection, line || lugs, load
Pvc Free:
Yes
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Ip Degree Of Protection:
front cover IP40 IEC 60529
Pollution Degree:
3 IEC 60947-1
Mounting Mode:
I-Line bracket)
Net Weight:
2.2 kg
Product Certifications:
UL || CSA || NOM
Breaking Capacity:
125 kA 240 V AC 50/60 Hz UL 489 || 100 kA 480 V AC 50/60 Hz UL 489 || 50 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 50 kA 500 V DC UL 489
Quantity Per Set:
1
Breaking Capacity Code:
L
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Utilisation Category:
category A
Quality Labels:
CE
Network Frequency:
50/60 Hz
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Mounting Support:
bracket
Control Type:
toggle
Depth:
86 mm
Circularity Profile:
ENVEOLI1311006EN
Warranty:
18 months
Height:
163 mm
Rohs Exemption Information:
Yes
Poles Description:
2P
Product Name:
PowerPact H
Sustainable Offer Status:
Green Premium product
Product Or Component Type:
circuit breaker
Eu Rohs Directive:
Compliant
Continuous Current Rating:
0.8
Line Rated Current:
15-15 A
Ambient Air Temperature For Operation:
-2-70 °C
Mercury Free:
Yes
Environmental Disclosure:
ENVPEP1311006EN
Circuit Breaker Application:
HACR rated
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Trip Unit Technology:
thermal-magnetic
Color:
Black
Magnetic Tripping Current:
750-750 A
Terminal Identifier:
AL150HD
Wire Stripping Length:
16 mm
Mounting Height:
4.5 in
Protected Poles Description:
2t
Range:
PowerPact
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Device Application:
distribution
Phase Connection:
BC
[Ics] Rated Service Breaking Capacity:
125 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 100 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 50 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Magnetic Hold Current:
350 A
Local Signalling:
switched off (OFF) 1 trip indicator green)
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Suitability For Isolation:
yes IEC 60947-2
Ambient Air Temperature For Storage:
-50-85 °C
Width:
104 mm
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Communication Interface:
Modbus || Ethernet
