Schneider Electric HLA260202 Molded Case Circuit Breaker 600V 20A

Schneider Electric HLA260202 Molded Case Circuit Breaker 600V 20A

Schneider Electric
SKU:
HLA260202
|
UPC:
785901553373
Availability:
Contact us to confirm availability and lead times.
$5,586.75
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 50kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. PowerPacT H I-Line circuit breakers are available in I-Line construction for easy installation and removal in I-Line applications. This breaker has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT H, 20A, 2 pole, circuit breaker has a breaking capacity of 50kA at 600VAC. This circuit breaker has a continuous current rating of 80% with an AC phase connection. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Mercury Free:
Yes
Poles Description:
2P
[Ics] Rated Service Breaking Capacity:
125 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 100 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 50 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Utilisation Category:
category A
Color:
Black
Ambient Air Temperature For Operation:
-2-70 °C
Local Signalling:
switched off (OFF) 1 trip indicator green)
Net Weight:
2.2 kg
Range:
PowerPact
Control Type:
toggle
Trip Unit Technology:
thermal-magnetic
Device Application:
distribution
Communication Interface:
Modbus || Ethernet
Quality Labels:
CE
Depth:
86 mm
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Height:
163 mm
Product Certifications:
UL || CSA || NOM
Mounting Support:
bracket
Continuous Current Rating:
0.8
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Breaking Capacity:
125 kA 240 V AC 50/60 Hz UL 489 || 100 kA 480 V AC 50/60 Hz UL 489 || 50 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 50 kA 500 V DC UL 489
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Electrical Connection:
I-Line connection, line || lugs, load
Protected Poles Description:
2t
Quantity Per Set:
1
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Phase Connection:
AC
Product Or Component Type:
circuit breaker
Network Frequency:
50/60 Hz
Eu Rohs Directive:
Compliant
Pvc Free:
Yes
Magnetic Tripping Current:
750-750 A
Width:
104 mm
Terminal Identifier:
AL150HD
Wire Stripping Length:
16 mm
Mounting Height:
4.5 in
Environmental Disclosure:
ENVPEP1311006EN
Sustainable Offer Status:
Green Premium product
Breaking Capacity Code:
L
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Product Name:
PowerPact H
Magnetic Hold Current:
350 A
Circularity Profile:
ENVEOLI1311006EN
Ip Degree Of Protection:
front cover IP40 IEC 60529
Suitability For Isolation:
yes IEC 60947-2
Circuit Breaker Application:
HACR rated
Line Rated Current:
20-20 A
Ambient Air Temperature For Storage:
-50-85 °C
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Mounting Mode:
I-Line bracket)
Rohs Exemption Information:
Yes
Warranty:
18 months
Pollution Degree:
3 IEC 60947-1
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
