Schneider Electric HLA36015 Molded Case Circuit Breaker 600V 15A

Schneider Electric HLA36015 Molded Case Circuit Breaker 600V 15A

Schneider Electric
SKU:
HLA36015
|
UPC:
785901700647
Availability:
Contact us to confirm availability and lead times.
$2,993.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 50kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. PowerPacT H I-Line circuit breakers are available in I-Line construction for easy installation and removal in I-Line applications. This breaker has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT H, 15A, 3 pole, circuit breaker has a breaking capacity of 50kA at 600VAC. This circuit breaker has a continuous current rating of 80% with an ABC phase connection. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Ambient Air Temperature For Storage:
-50-85 °C
Depth:
86 mm
Circularity Profile:
ENVEOLI2206027EN
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Sustainable Offer Status:
Green Premium product
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Magnetic Tripping Current:
750-750 A
Breaking Capacity Code:
L
Control Type:
toggle
Net Weight:
2.2 kg
Rohs Exemption Information:
Yes
Local Signalling:
switched off (OFF) 1 trip indicator green)
Environmental Disclosure:
ENVPEP2206027EN
Circuit Breaker Application:
HACR rated
Communication Interface:
Modbus || Ethernet
Mercury Free:
Yes
Suitability For Isolation:
yes IEC 60947-2
Device Application:
distribution
Poles Description:
3P
Range:
PowerPact
Wire Stripping Length:
16 mm
Mounting Support:
bracket
Product Certifications:
UL || CSA || NOM
Color:
Black
Line Rated Current:
15-15 A
Product Or Component Type:
circuit breaker
Terminal Identifier:
AL150HD
Trip Unit Technology:
thermal-magnetic
Pvc Free:
Yes
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Mounting Mode:
I-Line bracket)
Eu Rohs Directive:
Compliant with Exemptions
Warranty:
18 months
Quality Labels:
CE
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Ambient Air Temperature For Operation:
-2-70 °C
Electrical Connection:
I-Line connection, line || lugs, load
Continuous Current Rating:
0.8
Magnetic Hold Current:
350 A
Protected Poles Description:
3t
Mounting Height:
4.5 in
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Width:
104 mm
Utilisation Category:
category A
Breaking Capacity:
125 kA 240 V AC 50/60 Hz UL 489 || 100 kA 480 V AC 50/60 Hz UL 489 || 50 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 50 kA 500 V DC UL 489
Phase Connection:
ABC
Pollution Degree:
3 IEC 60947-1
Height:
163 mm
Quantity Per Set:
1
Network Frequency:
50/60 Hz
[Ics] Rated Service Breaking Capacity:
125 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 100 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 50 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Product Name:
PowerPact H
Ip Degree Of Protection:
front cover IP40 IEC 60529
