Schneider Electric HLL36015 Molded Case Circuit Breaker 600V 15A

Schneider Electric HLL36015 Molded Case Circuit Breaker 600V 15A

Schneider Electric
SKU:
HLL36015
|
UPC:
785901598879
Availability:
Contact us to confirm availability and lead times.
$2,849.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 50kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 15A, 3 pole, circuit breaker has a breaking capacity of 50kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Terminal Identifier:
AL150HD
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Ip Degree Of Protection:
front cover IP40 IEC 60529
Sustainable Offer Status:
Green Premium product
Mercury Free:
Yes
Local Signalling:
switched off (OFF) 1 trip indicator green)
Rohs Exemption Information:
Yes
Breaking Capacity Code:
L
Line Rated Current:
15-15 A
Suitability For Isolation:
yes IEC 60947-2
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Product Or Component Type:
circuit breaker
Circularity Profile:
ENVEOLI2206027EN
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Wire Stripping Length:
16 mm
Warranty:
18 months
Protected Poles Description:
3t
Mounting Mode:
unit mount lug)
Height:
163 mm
Depth:
86 mm
Continuous Current Rating:
0.8
Quantity Per Set:
1
Ambient Air Temperature For Operation:
-2-70 °C
Network Frequency:
50/60 Hz
Quality Labels:
CE
Product Name:
PowerPact H
Poles Description:
3P
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Trip Unit Technology:
thermal-magnetic
Utilisation Category:
category A
Magnetic Hold Current:
350 A
Width:
104 mm
Eu Rohs Directive:
Compliant with Exemptions
Electrical Connection:
lugs, line || lugs, load
[Ics] Rated Service Breaking Capacity:
125 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 100 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 50 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Pollution Degree:
3 IEC 60947-1
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Net Weight:
2.2 kg
Breaking Capacity:
125 kA 240 V AC 50/60 Hz UL 489 || 100 kA 480 V AC 50/60 Hz UL 489 || 50 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 50 kA 500 V DC UL 489
Mounting Support:
lug
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Environmental Disclosure:
ENVPEP2206027EN
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Color:
Black
Device Application:
distribution
Product Certifications:
UL || CSA || NOM
Circuit Breaker Application:
HACR rated
Ambient Air Temperature For Storage:
-50-85 °C
Control Type:
toggle
Pvc Free:
Yes
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Magnetic Tripping Current:
750-750 A
Range:
PowerPact
Communication Interface:
Modbus || Ethernet
