Schneider Electric HMIGK5310 10.4 Keypad Panel Vga-Tft
Schneider Electric
$6,292.03
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric HMIGK5310 10.4 Keypad Panel Vga-Tft
This Magelis GK keypad-touchscreen operator interface (HMI) is supplied with 24V DC, has a 10.4" color TFT LCD display with, 640 x 480 pixels (VGA), a complete keypad and 128MB EPROM. It also has 1 SD card slot, 1 host + 1 mini-B USB ports, 1 RS232C port, 1 RS485 port and 1 Ethernet TCP/IP port. It is ideal for complete control of an automation system in industry such as complex machines, CNC machines, food & beverage machines and pharmaceutical industry. The screen displays text messages, graphic objects and mimic diagrams, control and configuration of data. It also offers 18 dynamic function keys, 12 static function keys, 12 alphanumeric keys, 8 service keys and an industrial mouse pointer. Its RS485 host port makes it ideal to supervise and control simple systems and machines.
- Processor Frequency:
- 333 MHz
- Fixing Mode:
- by 12 spring clips
- Width:
- 296 mm
- Number Of Service Keys:
- 8
- China Rohs Regulation:
- X
- Local Signalling:
- for normal operation or backlighting faulty 1 LED (green or orange)
- Ambient Air Temperature For Storage:
- -20-60 °C
- Integrated Connection Type:
- <= 187.5 kbit/s RJ45, RS485 COM2 serial link Siemens MPI (187.5 kbits/s) || USB 2.0 type A master Modicon M340 terminal port communication || <= 115.2 kbits/s male SUB-D 9, RS232C COM1 serial link || removable screw terminal block power supply || RJ4
- Operating System:
- Harmony
- Shock Resistance:
- 15 gn 11 ms IEC 60068-2-27
- Display Size:
- 10.4 inch
- Vibration Resistance:
- 1 gn 9-150 Hz)IEC 60068-2-6 || 3.5 mm 5-9 Hz)IEC 60068-2-6
- Realtime Clock:
- built-in
- Character Font:
- Japanese (ANK, Kanji) || Korean || ASCII (European characters) || Taiwanese (traditional Chinese) || Chinese (simplified Chinese)
- Supply Voltage Limits:
- 19.2-28.8 V
- Enclosure Material:
- PPT
- Marking:
- CE
- Mercury Free:
- Yes
- Electromagnetic Compatibility:
- resistance to electrostatic discharge - test level: 4 kV level 3 conforming to IEC 61000-4-2 || resistance to radiated electromagnetic fields - test level: 10 V/m conforming to IEC 61000-4-3 || resistance to fast transient - test level: 2 kV level 3
- Ip Degree Of Protection:
- IP20 IEC 60529 rear panel) || IP65 IEC 60529 front panel)
- Brightness:
- 16 levels via touch panel
- Height:
- 332 mm
- Port Ethernet:
- 10BASE-T/100BASE-TX
- Number Of Static Function Keys:
- 12 with LED and labels
- Standards:
- IEC 61000-6-2 || IEC 61000-6-4 || CSA C22.2 No 213 || UL 61010-2-201 || ANSI/ISA 12.12.01 || IEC 61131-2
- Software Type:
- configuration software
- Software Designation:
- Vijeo Designer
- Range Of Product:
- Harmony GK
- Display Colour:
- 65536 colours
- Power Consumption In W:
- 11.4 W
- Memory Description:
- 512 KB SRAM back up of data lithium battery || 128 MB flash EPROM application memory
- Product Certifications:
- cULus || EAC || UL Class 1 Division 2 T5 || KC || UL Class 1 Division 2 T4A || RCM || CSA Class 1 Division 2 T4A || CSA Class 1 Division 2 T5 || UKCA
- Net Weight:
- 3.3 kg
- Relative Humidity:
- 10-90 % without condensation
- [Us] Rated Supply Voltage:
- 24 V DC
- Cut-Out Dimensions:
- 285 (+/- 0.4) x 309 (+/- 0.4) mm
- Front Material:
- aluminium alloy
- Rohs Exemption Information:
- Yes
- Operating Altitude:
- < 6561.68 ft (2000 m)
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Backlight Lifespan:
- 50000 hours
- Ambient Air Temperature For Operation:
- 0-55 °C
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Number Of Dynamic Function Keys Symb:
- 18 with LED
- Number Of Pages:
- limited by internal memory capacity
- Touch Panel:
- analogue
- Number Of Alphanumeric Keys:
- 12
- Display Type:
- backlit colour TFT LCD
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Downloadable Protocols:
- Telemecanique Modicon FIPWAY || Telemecanique Modicon Modbus Plus || Telemecanique Modicon Modbus TCP || Telemecanique Modicon Modbus || Mitsubishi Melsec third party protocols || Omron Sysmac third party protocols || Rockwell Automation Allen-Bradle
- Processor Name:
- CPU RISC
- Inrush Current:
- 30 A
- Display Resolution:
- 640 x 480 pixels VGA
- Supply:
- external source
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Mounting Mode:
- flush mounting
- Nema Degree Of Protection:
- NEMA 4X front panel (indoor use)
- Immunity To Microbreaks:
- 10 ms
- Product Or Component Type:
- touchscreen panel with keypad
- Depth:
- 76 mm
- Memory Type:
- up to 32 GB SD card RAM || up to 32 GB SDHC card RAM
- Touch Sensitive Zone:
- 1024 x 1024
