40-55 °C with power derating of 2 % per °C) || 0-40 °C without derating)
Network Type:
DC
Speed Feedback Resolution:
20000 points/turn
Motor Flange Size:
57 mm
Shaft Length:
21 mm
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Discrete Output Voltage:
23...25 V
Maximum Switching Current:
100 mA per output || 200 mA total
Ambient Air Temperature For Storage:
-25-70 °C
Winding Type:
medium speed of rotation and medium torque
Continuous Stall Torque:
0.45 N.m
Length:
101.9 mm
Transmission Rate:
100 Mbits
Discrete Input Current:
10-10 mA at 24 V safety input || 2-2 mA at 24 V 24 V signal interface
Peak Stall Torque:
0.45 N.m
Vibration Resistance:
20 m/s² 10-500 Hz) 10 cycles EN/IEC 60068-2-6
Number Of Motor Poles:
6
Relative Humidity:
15-85 % without condensation
Mercury Free:
Yes
Gear Box Type:
without
Device Short Name:
ILS
Sustainable Offer Status:
Green Premium product
Associated Fuse Rating:
16 A
[Us] Rated Supply Voltage:
48 V || 24 V
Rohs Exemption Information:
Yes
Range Of Product:
Lexium integrated drive
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Net Weight:
1.3 kg
Rotor Inertia:
0.1 kg.cm²
Feedback Type:
index pulse
Voltage State 1 Guaranteed:
15...30 V
Nominal Speed:
1000 rpm 24 V || 2000 rpm 48 V
Current Consumption:
3500 mA maximum continuous
Holding Torque:
0.45 N.m
Operating Altitude:
<= 3280.84 ft (1000 m) without derating
China Rohs Regulation:
X
Marking:
CE
Shaft End:
untapped
Nominal Torque:
0.45 N.m
Shaft Diameter:
6.35 mm
Warranty:
18 months
Supply Voltage Limits:
18-55 V
Holding Brake:
without
Permissible Ambient Air Temperature Around The Device:
105 °C power amplifier || 110 °C motor
Maximum Axial Force Fa:
100 N tensile force) || 8.4 N force pressure)
Mounting Holes Diameter:
5.2 mm
Phase:
single phase
Service Life In Hours:
20000 h bearing
Maximum Mechanical Speed:
3000 rpm
Protection Type:
safe torque off || overload of output voltage || short circuit of the output voltage
