Schneider Electric JDF36150 Molded Case Circuit Breaker 600V 150A

Schneider Electric JDF36150 Molded Case Circuit Breaker 600V 150A

Schneider Electric
SKU:
JDF36150
|
UPC:
785901906254
Availability:
Contact us to confirm availability and lead times.
$2,730.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT J-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT J-Frame circuit breakers are available with either thermal magnetic or MicroLogic electronic trip protection units. This PowerPacT J-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600VAC. All PowerPacT J-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT J circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has a busbar connection. This PowerPacT J, 150A, 3 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT J circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Line Rated Current:
150-150 A
Height:
191 mm
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Mercury Free:
Yes
Tightening Torque:
25-25 N.m 25-95 mm² (AWG 4...AWG 4/0)
Quality Labels:
CE
Long Time Pick-Up Adjustment Range:
0.25...1 x In
Pvc Free:
Yes
Terminal Identifier:
AL175JD
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Phase Connection:
CB
Suitability For Isolation:
yes IEC 60947-2
Width:
104 mm
Circuit Breaker Application:
HACR rated
Communication Interface:
Modbus || Ethernet
[Ue] Rated Operational Voltage:
600 V AC 50/60 Hz IEC 60947-3
Range:
PowerPact
Depth:
86 mm
Product Name:
PowerPact J
Breaking Capacity:
25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC
Rohs Exemption Information:
Yes
Utilisation Category:
category A
Network Frequency:
50/60 Hz
Warranty:
18 months
Mounting Mode:
unit mount busbar)
Device Application:
distribution
Sustainable Offer Status:
Green Premium product
Circularity Profile:
ENVEOLI2206031EN
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Environmental Disclosure:
ENVPEP2206031EN
Awg Gauge:
AWG 4...AWG 4/0 aluminium/copper terminal
Net Weight:
2.4 kg
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Continuous Current Rating:
0.8
Trip Unit Technology:
thermal-magnetic
Mounting Height:
4.5 in
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Product Or Component Type:
circuit breaker
Local Signalling:
switched off (OFF) 1 trip indicator green)
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Poles Description:
3P
Mounting Support:
busbar
Ambient Air Temperature For Operation:
-2-70 °C
Electrical Connection:
busbar connection, line || busbar connection, load
Protection Type:
overload protection || short-circuit protection
Ambient Air Temperature For Storage:
-50-85 °C
Pollution Degree:
3 IEC 60947-1
Magnetic Hold Current:
750 A
Product Certifications:
UL || CSA || NOM
Breaking Capacity Code:
D
[Ics] Rated Service Breaking Capacity:
25 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Control Type:
toggle
Eu Rohs Directive:
Compliant with Exemptions
Ip Degree Of Protection:
front cover IP40
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Magnetic Tripping Current:
1750-1750 A
Wire Stripping Length:
25 mm
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
