Schneider Electric JGL37175D81 Molded Case Circuit Breaker 500Vdc 175A

Schneider Electric JGL37175D81 Molded Case Circuit Breaker 500Vdc 175A

Schneider Electric
SKU:
JGL37175D81
|
UPC:
785901985891
Availability:
Contact us to confirm availability and lead times.
$3,779.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT J-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT J-Frame circuit breakers are available with either thermal magnetic or MicroLogic electronic trip protection units. This PowerPacT J-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 20kA at 500VDC. All PowerPacT J-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT J circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT J, 175A, 3 pole, circuit breaker has a breaking capacity of 20kA at 500VDC. This circuit breaker has a continuous current rating of 80%. PowerPacT J circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Trip Unit Technology:
thermal-magnetic
Range:
PowerPact
Electrical Connection:
lugs, line || lugs, load
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Long Time Pick-Up Adjustment Range:
0.25...1 x In
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Local Signalling:
switched off (OFF) 1 trip indicator green)
Width:
104 mm
Eu Rohs Directive:
Compliant with Exemptions
Ip Degree Of Protection:
front cover IP40
Ambient Air Temperature For Storage:
-50-85 °C
Product Or Component Type:
Motor Circuit Protector
Continuous Current Rating:
0.8
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Communication Interface:
Modbus || Ethernet
Net Weight:
2.4 kg
Poles Description:
3P
Depth:
86 mm
Magnetic Tripping Current:
350-600 A
Terminal Identifier:
AL175JD
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Mounting Mode:
unit mount lug)
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Product Name:
PowerPact J
Warranty:
18 months
[Ue] Rated Operational Voltage:
600 V AC 50/60 Hz IEC 60947-3
Mercury Free:
Yes
[Ics] Rated Service Breaking Capacity:
65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Utilisation Category:
category A
Sustainable Offer Status:
Green Premium product
Awg Gauge:
AWG 4...AWG 4/0 aluminium/copper terminal
Suitability For Isolation:
yes IEC 60947-2
Pvc Free:
Yes
Mounting Support:
lug
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Device Application:
distribution
Pollution Degree:
3 IEC 60947-1
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Ambient Air Temperature For Operation:
-2-70 °C
Environmental Disclosure:
ENVPEP2206031EN
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Breaking Capacity:
65 kA 240 V AC 50/60 Hz UL 489 || 35 kA 480 V AC 50/60 Hz UL 489 || 18 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 20 kA 500 V DC UL 489
Quality Labels:
CE
Circularity Profile:
ENVEOLI2206031EN
Breaking Capacity Code:
G
Line Rated Current:
175-175 A
Rohs Exemption Information:
Yes
Product Certifications:
UL || CSA || NOM
Protection Type:
overload protection || short-circuit protection
Network Frequency:
50/60 Hz
Control Type:
toggle
Wire Stripping Length:
25 mm
Height:
191 mm
Tightening Torque:
25-25 N.m 25-95 mm² (AWG 4...AWG 4/0)
