Schneider Electric JGM36200 Molded Case Circuit Breaker 600V 200A

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric JGM36200 Molded Case Circuit Breaker 600V 200A

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

JGM36200

UPC:

785901583059

MPN:

Condition:

New

Mounting Support:

lug

Depth:

86 mm

Phase Connection:

ABC

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Product Certifications:

UL || CSA || NOM

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Circuit Breaker Application:

HACR rated

California Proposition 65:

WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information

Local Signalling:

switched off (OFF) 1 trip indicator green)

Line Rated Current:

200-200 A

Warranty:

18 months

Network Frequency:

50/60 Hz

Width:

104 mm

Product Name:

PowerPact J

Utilisation Category:

category A

Mounting Mode:

unit mount lug)

Continuous Current Rating:

0.8

Protection Type:

overload protection || short-circuit protection

Control Type:

toggle

Magnetic Tripping Current:

2000-2000 A

[Uimp] Rated Impulse Withstand Voltage:

8 kV IEC 60947-2

Ambient Air Temperature For Operation:

-2-70 °C

Trip Unit Technology:

thermal-magnetic

Long Time Pick-Up Adjustment Range:

0.25...1 x In

Height:

191 mm

Quality Labels:

CE

Wire Stripping Length:

25 mm

Pollution Degree:

3 IEC 60947-1

Magnetic Hold Current:

1000 A

[Ui] Rated Insulation Voltage:

750 V IEC 60947-2

Device Application:

distribution

Environmental Disclosure:

ENVPEP2206031EN

Pvc Free:

Yes

Net Weight:

2.4 kg

Ip Degree Of Protection:

front cover IP40

Tightening Torque:

25-25 N.m 95-185 mm² (AWG 3/0...350 kcmil)

Communication Interface:

Modbus || Ethernet

Electrical Connection:

lugs, line || terminal nut, load

[Ue] Rated Operational Voltage:

600 V AC 50/60 Hz IEC 60947-3

Awg Gauge:

AWG 3/0...350 kcmil aluminium/copper terminals

Suitability For Isolation:

yes IEC 60947-2

[Ics] Rated Service Breaking Capacity:

65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2

Number Of Slots:

2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)

Sustainable Offer Status:

Green Premium product

Breaking Capacity:

65 kA 240 V AC 50/60 Hz UL 489 || 35 kA 480 V AC 50/60 Hz UL 489 || 18 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 20 kA 500 V DC UL 489

Poles Description:

3P

Mercury Free:

Yes

Mounting Height:

4.5 in

Circularity Profile:

ENVEOLI2206031EN

Rohs Exemption Information:

Yes

Terminal Identifier:

AL250JD

Range:

PowerPact

Operating Altitude:

< 6561.68 ft (2000 m) without derating || 5000 m with derating

Product Or Component Type:

circuit breaker

Breaking Capacity Code:

G

Eu Rohs Directive:

Compliant with Exemptions

Standards:

UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
