Schneider Electric JJF36200 Molded Case Circuit Breaker 600V 200A
Schneider Electric
$8,148.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
PowerPacT J-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT J-Frame circuit breakers are available with either thermal magnetic or MicroLogic electronic trip protection units. This PowerPacT J-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 25kA at 600VAC. All PowerPacT J-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT J circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has a busbar connection. This PowerPacT J, 200A, 3 pole, circuit breaker has a breaking capacity of 25kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT J circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
- Sustainable Offer Status:
- Green Premium product
- Mounting Support:
- busbar
- [Ui] Rated Insulation Voltage:
- 750 V IEC 60947-2
- Circuit Breaker Application:
- HACR rated
- Number Of Slots:
- 2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
- Magnetic Tripping Current:
- 2000-2000 A
- Product Certifications:
- UL || CSA || NOM
- Ambient Air Temperature For Storage:
- -50-85 °C
- Mounting Height:
- 4.5 in
- [Uimp] Rated Impulse Withstand Voltage:
- 8 kV IEC 60947-2
- Suitability For Isolation:
- yes IEC 60947-2
- Breaking Capacity:
- 100 kA 240 V AC 50/60 Hz UL 489 || 65 kA 480 V AC 50/60 Hz UL 489 || 25 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489
- Environmental Disclosure:
- ENVPEP2206031EN
- Breaking Capacity Code:
- J
- Pollution Degree:
- 3 IEC 60947-1
- Rohs Exemption Information:
- Yes
- Device Application:
- distribution
- Network Frequency:
- 50/60 Hz
- Control Type:
- toggle
- Circularity Profile:
- ENVEOLI2206031EN
- Depth:
- 86 mm
- Mounting Mode:
- unit mount busbar)
- Line Rated Current:
- 200-200 A
- Phase Connection:
- BA
- Standards:
- UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
- Trip Unit Technology:
- thermal-magnetic
- Height:
- 191 mm
- [Ics] Rated Service Breaking Capacity:
- 65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
- Communication Interface:
- Modbus || Ethernet
- Tightening Torque:
- 25-25 N.m 95-185 mm² (AWG 3/0...350 kcmil)
- Eu Rohs Directive:
- Compliant with Exemptions
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
- Net Weight:
- 2.4 kg
- Mercury Free:
- Yes
- Terminal Identifier:
- AL250JD
- Warranty:
- 18 months
- Product Or Component Type:
- circuit breaker
- Electrical Connection:
- busbar connection, line || busbar connection, load
- Continuous Current Rating:
- 0.8
- Magnetic Hold Current:
- 1000 A
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Utilisation Category:
- category A
- Poles Description:
- 3P
- Quality Labels:
- CE
- Ambient Air Temperature For Operation:
- -2-70 °C
- Wire Stripping Length:
- 25 mm
- Local Signalling:
- switched off (OFF) 1 trip indicator green)
- [Ue] Rated Operational Voltage:
- 600 V AC 50/60 Hz IEC 60947-3
- Product Name:
- PowerPact J
- Operating Altitude:
- < 6561.68 ft (2000 m) without derating || 5000 m with derating
- Long Time Pick-Up Adjustment Range:
- 0.25...1 x In
- Pvc Free:
- Yes
- Ip Degree Of Protection:
- front cover IP40
- Awg Gauge:
- AWG 3/0...350 kcmil aluminium/copper terminals
- Width:
- 104 mm
- Range:
- PowerPact
- Protection Type:
- overload protection || short-circuit protection
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
