Schneider Electric JJL36200LY Molded Case Circuit Breaker 600V 200A

Schneider Electric JJL36200LY Molded Case Circuit Breaker 600V 200A

Schneider Electric
SKU:
JJL36200LY
|
UPC:
785901953425
Availability:
Contact us to confirm availability and lead times.
$5,432.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT J-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT J-Frame circuit breakers are available with either thermal magnetic or MicroLogic electronic trip protection units. This PowerPacT J-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 25kA at 600VAC. All PowerPacT J-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT J circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT J, 200A, 3 pole, circuit breaker has a breaking capacity of 25kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT J circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Breaking Capacity:
100 kA 240 V AC 50/60 Hz UL 489 || 65 kA 480 V AC 50/60 Hz UL 489 || 25 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489
Continuous Current Rating:
0.8
Warranty:
18 months
Width:
104 mm
Protection Type:
overload protection || short-circuit protection
Accessory / Separate Part Type:
low amperage lug
Long Time Pick-Up Adjustment Range:
0.25...1 x In
Rohs Exemption Information:
Yes
Electrical Connection:
lugs, line || lugs, load
Line Rated Current:
200-200 A
Circularity Profile:
ENVEOLI2206031EN
Pollution Degree:
3 IEC 60947-1
Net Weight:
2.4 kg
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Range:
PowerPact
Phase Connection:
ABC
Mounting Support:
lug
Mounting Height:
4.5 in
Suitability For Isolation:
yes IEC 60947-2
Product Name:
PowerPact J
Ambient Air Temperature For Storage:
-50-85 °C
Environmental Disclosure:
ENVPEP2206031EN
Magnetic Tripping Current:
2000-2000 A
Local Signalling:
switched off (OFF) 1 trip indicator green)
Mercury Free:
Yes
Quality Labels:
CE
Height:
191 mm
Device Application:
distribution
Eu Rohs Directive:
Compliant with Exemptions
Tightening Torque:
25-25 N.m 95-185 mm² (AWG 3/0...350 kcmil)
Terminal Identifier:
AL250JD
Utilisation Category:
category A
Ambient Air Temperature For Operation:
-2-70 °C
Breaking Capacity Code:
J
Product Or Component Type:
circuit breaker
Ip Degree Of Protection:
front cover IP40
Network Frequency:
50/60 Hz
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Pvc Free:
Yes
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Mounting Mode:
unit mount lug)
Communication Interface:
Modbus || Ethernet
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Trip Unit Technology:
thermal-magnetic
Poles Description:
3P
Awg Gauge:
AWG 3/0...350 kcmil aluminium/copper terminals
[Ics] Rated Service Breaking Capacity:
65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Sustainable Offer Status:
Green Premium product
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
[Ue] Rated Operational Voltage:
600 V AC 50/60 Hz IEC 60947-3
Control Type:
toggle
Wire Stripping Length:
25 mm
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Circuit Breaker Application:
HACR rated
Depth:
86 mm
Magnetic Hold Current:
1000 A
Product Certifications:
UL || CSA || NOM
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
