Schneider Electric JJL36225C Molded Case Circuit Breaker 600V 225A

Schneider Electric JJL36225C Molded Case Circuit Breaker 600V 225A

Schneider Electric
SKU:
JJL36225C
|
UPC:
785901484936
Availability:
Factory stock
$4,154.88
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT J-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT J-Frame circuit breakers are available with either thermal magnetic or MicroLogic electronic trip protection units. This PowerPacT J-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 25kA at 600VAC. All PowerPacT J-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT J circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT J, 225A, 3 pole, circuit breaker has a breaking capacity of 25kA at 600VAC. This circuit breaker has a continuous current rating of 100%. PowerPacT J circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Local Signalling:
switched off (OFF) 1 trip indicator green)
Protection Type:
overload protection || short-circuit protection
Long Time Pick-Up Adjustment Range:
0.25...1 x In
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Range:
PowerPact
Magnetic Hold Current:
1125 A
Network Frequency:
50/60 Hz
Quality Labels:
CE
Circularity Profile:
ENVEOLI2206031EN
[Ue] Rated Operational Voltage:
600 V AC 50/60 Hz IEC 60947-3
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Line Rated Current:
225-225 A
Ambient Air Temperature For Storage:
-50-85 °C
Depth:
86 mm
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Environmental Disclosure:
ENVPEP2206031EN
Trip Unit Technology:
thermal-magnetic
Tightening Torque:
25-25 N.m 95-185 mm² (AWG 3/0...350 kcmil)
Pvc Free:
Yes
Ip Degree Of Protection:
front cover IP40
Suitability For Isolation:
yes IEC 60947-2
Device Application:
distribution
Wire Stripping Length:
25 mm
Product Name:
PowerPact J
Magnetic Tripping Current:
2250-2250 A
Mounting Support:
lug
Awg Gauge:
AWG 3/0...350 kcmil aluminium/copper terminals
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Product Or Component Type:
circuit breaker
Mounting Mode:
unit mount lug)
Product Certifications:
UL || CSA || NOM
Sustainable Offer Status:
Green Premium product
Utilisation Category:
category A
Electrical Connection:
lugs, line || lugs, load
Pollution Degree:
3 IEC 60947-1
Mercury Free:
Yes
Breaking Capacity:
100 kA 240 V AC 50/60 Hz UL 489 || 65 kA 480 V AC 50/60 Hz UL 489 || 25 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489
Width:
104 mm
Ambient Air Temperature For Operation:
-2-70 °C
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Communication Interface:
Modbus || Ethernet
[Ics] Rated Service Breaking Capacity:
65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Height:
191 mm
Eu Rohs Directive:
Compliant with Exemptions
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Poles Description:
3P
Continuous Current Rating:
1
Control Type:
toggle
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Terminal Identifier:
AL250JD
Rohs Exemption Information:
Yes
Breaking Capacity Code:
J
Circuit Breaker Application:
HACR rated
Warranty:
18 months
Net Weight:
2.4 kg
